Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | PLC-5 |
| Model Number | 1785-L40B |
| Product Type | PLC Processor Module |
| Processor Model | PLC-5/40 |
| Processor Type | Enhanced PLC-5 Controller |
| User Memory | 48K Words |
| Programming Software | RSLogix 5 |
| Chassis Compatibility | 1771 I/O Chassis |
| Supported I/O Capacity | Up to 2048 I/O Points |
| Local I/O Chassis | Up to 4 |
| Remote I/O Chassis | Up to 28 |
| Communication Ports | DH+, Remote I/O, RS-232-C Serial |
| Network Support | Data Highway Plus (DH+), Remote I/O |
| Communication Speed | Up to 230.4 kbps |
| Battery-backed RAM | Yes |
| Keyswitch Modes | RUN, PROG, REM |
| LED Indicators | PROC, BATT, FORCE, COMM |
| Backplane Current Draw | Approx. 3.3 A @ 5V DC |
| Power Dissipation | Approx. 17 W |
| Mounting Type | 1771 Chassis Mount |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Certifications | UL, CSA, CE, C-Tick |
| Lifecycle Status | Discontinued |
| Actual Dimensions (H × W × D) | Approx. 279 × 76 × 152 mm |
| Actual Weight | Approx. 1.42 kg |
| Typical Applications | Legacy Industrial Automation, Process Control, Factory Automation |
FAQ
FAQ
Q1: What is the Allen-Bradley 1785-L40B used for?
A1: The 1785-L40B is a PLC-5/40 programmable controller processor module used in legacy Allen-Bradley PLC-5 industrial automation systems.
Q2: How much memory does the 1785-L40B provide?
A2: The controller provides approximately 48K words of user memory for ladder logic programs and data storage.
Q3: Which communication networks are supported by the 1785-L40B?
A3: The processor supports DH+ (Data Highway Plus), Remote I/O, and RS-232 serial communications.
Q4: Is the 1785-L40B still available from Rockwell Automation?
A4: No. The 1785-L40B has been discontinued by Rockwell Automation.
Q5: What are the actual dimensions of the 1785-L40B?
A5: The approximate dimensions are 279 × 76 × 152 mm (H × W × D).
Q6: What is the actual weight of the 1785-L40B?
A6: The actual weight is approximately 1.42 kg (3 lb 2 oz).
Q7: What chassis does the 1785-L40B install into?
A7: The processor installs into Allen-Bradley 1771 series PLC chassis systems.
Q8: What are common applications for the 1785-L40B?
A8: Common applications include factory automation, process control, manufacturing systems, and legacy PLC-5 based industrial control systems.
