Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | FLEX Ex |
| Model Number | 1797-BCNR |
| Product Type | FLEX Ex Redundant ControlNet Adapter |
| Communication Protocol | ControlNet |
| Adapter Type | Redundant Network Adapter |
| Media Support | Coaxial ControlNet |
| Redundancy Support | Yes |
| Number of Supported I/O Modules | Up to 8 FLEX Ex I/O Modules |
| Communication Rate | 5 Mbps |
| Power Supply Requirement | 24V DC |
| Input Voltage Range | 18.5 to 32V DC |
| Current Consumption | Approx. 400 mA |
| Backplane Current | FLEX Ex Backplane Powered |
| Isolation Voltage | 500V DC |
| Status Indicators | Module Status, Network Status, Redundancy Status LEDs |
| Hazardous Area Certification | Intrinsically Safe System Support |
| Compatible Modules | FLEX Ex 1797 Series I/O Modules |
| Mounting Type | DIN Rail Mount |
| Enclosure Type | Open Style |
| Protection Rating | IP20 |
| Operating Temperature | -20°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Shock Resistance | 30 G Operating |
| Vibration Resistance | 5 G at 10 to 500 Hz |
| Certifications | UL, CE, ATEX, IECEx, FM, CSA |
| Lifecycle Status | Discontinued |
| Dimensions | Approx. 94 x 94 x 87 mm |
| Weight | Approx. 0.35 kg |
| Typical Applications | Hazardous Area Automation, Oil & Gas, Chemical Processing, Redundant Process Control |
FAQ
FAQ
Q1: What is the Allen-Bradley 1797-BCNR used for?
A1: The 1797-BCNR is a FLEX Ex redundant ControlNet adapter used to connect FLEX Ex intrinsically safe I/O modules to a ControlNet network in hazardous industrial environments.
Q2: What communication protocol does the 1797-BCNR support?
A2: The module supports the Allen-Bradley ControlNet industrial communication protocol with redundant media capability.
Q3: Does the 1797-BCNR support network redundancy?
A3: Yes. The adapter supports redundant ControlNet communication for increased system reliability and process uptime.
Q4: Which I/O modules are compatible with the 1797-BCNR?
A4: The adapter is designed for use with Allen-Bradley FLEX Ex 1797 series intrinsically safe I/O modules.
Q5: Is the 1797-BCNR suitable for hazardous locations?
A5: Yes. The module is specifically designed for hazardous-area automation systems and supports intrinsically safe installations with ATEX, IECEx, FM, and CSA certifications.
Q6: How many FLEX Ex modules can the 1797-BCNR support?
A6: The adapter can support up to 8 FLEX Ex I/O modules on the FLEX Ex backplane.
Q7: What mounting method is used for the 1797-BCNR?
A7: The module is designed for DIN rail mounting inside industrial automation cabinets and hazardous-area control systems.
Q8: What are the common applications of the 1797-BCNR?
A8: Common applications include oil and gas production, chemical processing plants, offshore platforms, refinery automation, and hazardous-area distributed I/O systems.
