Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Micro850 |
| Model Number | 2080-L50E-48QWB |
| Product Type | Programmable Logic Controller (PLC) |
| Controller Family | Micro850 Ethernet Controller |
| Embedded I/O | 48 Points |
| Digital Inputs | 28 × 24V DC Inputs |
| Analog Inputs | 4 × Analog Inputs (0–10V DC) |
| Relay Outputs | 20 Relay Outputs |
| Input Power Supply | 24V DC |
| Ethernet Port | 1 × EtherNet/IP Port |
| USB Port | USB Programming Port |
| Communication Protocols | EtherNet/IP, Modbus TCP, CIP |
| Expansion I/O Support | Up to 5 Plug-in / Expansion Modules |
| Memory Capacity | 20 KB User Memory |
| Real-Time Clock | Integrated |
| Programming Software | Connected Components Workbench (CCW) |
| Programming Languages | Ladder Diagram, Function Block, Structured Text |
| High-Speed Inputs | Supported |
| PTO/PWM Outputs | Supported |
| Mounting Type | DIN Rail or Panel Mount |
| Enclosure Type | Open Style |
| Protection Rating | IP20 |
| Operating Temperature | -20°C to 65°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Shock Resistance | 30 G |
| Vibration Resistance | 5 G at 10 to 500 Hz |
| Certifications | UL, CE, CSA, KC |
| Lifecycle Status | Active |
| Approximate Dimensions (H × W × D) | 90 × 225 × 87 mm |
| Approximate Weight | 0.85 kg |
| Typical Applications | Machine Control, Packaging, Conveyors, OEM Automation |
FAQ
FAQ
Q1: What is the Allen-Bradley 2080-L50E-48QWB used for?
A1: The 2080-L50E-48QWB is a Micro850 programmable logic controller used for small-to-medium industrial machine automation and process control applications.
Q2: How many built-in I/O points does the 2080-L50E-48QWB provide?
A2: The controller includes 48 embedded I/O points consisting of digital inputs, analog inputs, and relay outputs.
Q3: Does the 2080-L50E-48QWB support Ethernet communication?
A3: Yes. The controller includes an embedded EtherNet/IP communication port supporting industrial Ethernet networking and Modbus TCP communication.
Q4: What type of outputs are included in the 2080-L50E-48QWB?
A4: The controller provides 20 relay outputs for controlling industrial loads and devices.
Q5: Which software is used to program the 2080-L50E-48QWB?
A5: The controller is programmed using Allen-Bradley Connected Components Workbench (CCW) software.
Q6: Does the 2080-L50E-48QWB support expansion modules?
A6: Yes. The controller supports up to 5 expansion or plug-in modules for additional I/O and communication capability.
Q7: What are the dimensions and weight of the 2080-L50E-48QWB?
A7: The controller dimensions are approximately 90 × 225 × 87 mm and the weight is approximately 0.85 kg.
Q8: What are common applications of the 2080-L50E-48QWB?
A8: Common applications include packaging machines, conveyor systems, pump control, OEM equipment, material handling, and general industrial automation systems.
