Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Micro820 |
| Model Number | 2080-LC20-20QBB |
| Product Type | Programmable Logic Controller (PLC) |
| Controller Family | Micro820 Ethernet Controller |
| Embedded I/O | 20 Points |
| Digital Inputs | 12 × 24V DC Inputs |
| Digital Outputs | 7 × 24V DC Source Outputs |
| Analog Inputs | 4 × Configurable Analog Inputs (0…10V DC / Thermistor Support) |
| Analog Outputs | 1 × Analog Output (0…10V DC) |
| Power Supply | 24V DC |
| Power Supply Voltage Range | 20.4…26.4V DC |
| Ethernet Port | 1 × EtherNet/IP Port |
| Serial Port | RS-232 / RS-485 Non-isolated |
| Communication Protocols | EtherNet/IP, Modbus RTU/TCP, CIP |
| Memory Capacity | 10 KB Program / 20 KB Data |
| Expansion Support | Up to 2 Plug-in Modules |
| MicroSD Support | Yes |
| Real-Time Clock | Embedded RTC |
| PWM Output | 5 kHz PWM Supported |
| Programming Software | Connected Components Workbench (CCW) |
| Programming Languages | Ladder Diagram, Function Block, Structured Text |
| Mounting Type | DIN Rail or Panel Mount |
| Enclosure Type | Open Style |
| Protection Rating | IP20 |
| Power Dissipation | 6 W |
| Operating Temperature | -20°C to 65°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Certifications | UL, CE, CSA, KC |
| Lifecycle Status | Active |
| Dimensions (H × W × D) | 90 × 104 × 75 mm |
| Approximate Weight | 0.38 kg |
| Typical Applications | Small Machine Control, OEM Equipment, Pumps, Conveyors, Packaging Systems |
FAQ
FAQ
Q1: What is the Allen-Bradley 2080-LC20-20QBB used for?
A1: The 2080-LC20-20QBB is a Micro820 programmable controller designed for small machine automation and compact industrial control systems.
Q2: How many I/O points are built into the 2080-LC20-20QBB?
A2: The controller includes 20 embedded I/O points consisting of 12 digital inputs, 7 digital outputs, and 1 analog output plus 4 configurable analog inputs.
Q3: Does the 2080-LC20-20QBB support Ethernet communication?
A3: Yes. The controller includes an embedded EtherNet/IP communication port and also supports RS-232/RS-485 serial communication.
Q4: What software is used to program the 2080-LC20-20QBB?
A4: The controller is programmed using Connected Components Workbench (CCW) software from.
Q5: Does the controller support expansion modules?
A5: Yes. The Micro820 controller supports up to two Micro800 plug-in modules for additional functionality.
Q6: What are the actual dimensions of the 2080-LC20-20QBB?
A6: The controller dimensions are 90 × 104 × 75 mm (3.54 × 4.09 × 2.95 in.).
Q7: What is the approximate weight of the 2080-LC20-20QBB?
A7: The approximate shipping weight is 0.38 kg (0.83 lb).
Q8: What are common applications for the 2080-LC20-20QBB?
A8: Common applications include packaging machines, material handling equipment, conveyor systems, HVAC control, pump systems, and OEM automation equipment.
