Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Micro820 |
| Model Number | 2080-LC20-20QWB |
| Product Type | Programmable Logic Controller (PLC) |
| Controller Family | Micro820 Ethernet Controller |
| Embedded I/O | 20 Points |
| Digital Inputs | 12 × 24V DC Inputs |
| Digital Outputs | 7 × Relay Outputs |
| Analog Inputs | 4 × Configurable Analog Inputs (0…10V DC / Thermistor Support) |
| Analog Outputs | 1 × Analog Output (0…10V DC) |
| Power Supply | 24V DC |
| Power Supply Voltage Range | 20.4…26.4V DC |
| Ethernet Port | 1 × Embedded EtherNet/IP Port |
| Serial Port | RS-232 / RS-485 Non-isolated |
| Communication Protocols | EtherNet/IP, Modbus RTU, Modbus TCP, CIP |
| Expansion Support | Up to 2 Plug-in Modules |
| MicroSD Support | Yes |
| Real-Time Clock | Embedded RTC |
| PWM Output | Supported |
| Programming Software | Connected Components Workbench (CCW) |
| Programming Languages | Ladder Diagram, Function Block, Structured Text |
| Terminal Type | Fixed Terminal Block |
| Mounting Type | DIN Rail or Panel Mount |
| Enclosure Type | Open Style |
| Protection Rating | IP20 |
| Power Dissipation | 6 W |
| Operating Temperature | -20°C to 65°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Certifications | UL, CE, CSA, KC |
| Lifecycle Status | Active |
| Actual Dimensions (H × W × D) | 90 × 104 × 75 mm |
| Actual Weight | Approx. 0.38 kg |
| Typical Applications | Small Machine Control, OEM Equipment, Conveyors, Pumps, Packaging Systems |
FAQ
FAQ
Q1: What is the Allen-Bradley 2080-LC20-20QWB used for?
A1: The 2080-LC20-20QWB is a Micro820 programmable controller designed for compact industrial automation and OEM machine control applications.
Q2: How many built-in I/O points does the 2080-LC20-20QWB provide?
A2: The controller includes 20 embedded I/O points consisting of 12 digital inputs, 7 relay outputs, and integrated analog I/O.
Q3: Does the 2080-LC20-20QWB support Ethernet communication?
A3: Yes. The controller includes an embedded EtherNet/IP communication port and RS-232/RS-485 serial communication.
Q4: What programming software is used with the 2080-LC20-20QWB?
A4: The controller is programmed using Connected Components Workbench (CCW) software from Rockwell Automation.
Q5: What are the actual dimensions of the 2080-LC20-20QWB?
A5: The actual controller dimensions are 90 × 104 × 75 mm (3.54 × 4.09 × 2.95 in.).
Q6: What is the actual weight of the 2080-LC20-20QWB?
A6: The approximate shipping weight is 0.38 kg (0.83 lb).
Q7: Does the 2080-LC20-20QWB support expansion modules?
A7: Yes. The controller supports Micro800 plug-in modules for additional functionality and expansion capability.
Q8: What are common applications for the 2080-LC20-20QWB?
A8: Common applications include conveyor systems, packaging machinery, HVAC control, pump automation, and OEM industrial equipment.
