Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Micro850 |
| Model Number | 2080-LC50-24QWB |
| Product Type | Programmable Logic Controller (PLC) |
| Controller Family | Micro850 Ethernet Controller |
| Embedded I/O | 24 Points |
| Digital Inputs | 14 × 24V DC Inputs |
| Analog Inputs | 4 × Analog Inputs (0…10V DC) |
| Digital Outputs | 10 × Relay Outputs |
| Power Supply | 24V DC |
| Power Supply Voltage Range | 20.4…26.4V DC |
| Ethernet Port | 1 × Embedded EtherNet/IP Port |
| USB Port | USB 2.0 Programming Port |
| Serial Port | RS-232 / RS-485 |
| Communication Protocols | EtherNet/IP, Modbus TCP, Modbus RTU, CIP |
| Expansion Capability | Up to 5 Expansion I/O Modules |
| Plug-in Module Support | Supported |
| Memory Capacity | 20 KB User Program Memory |
| Real-Time Clock | Embedded RTC |
| High-Speed Counters | Supported |
| PTO/PWM Outputs | Supported |
| Programming Software | Connected Components Workbench (CCW) |
| Programming Languages | Ladder Diagram, Function Block, Structured Text |
| Mounting Type | DIN Rail or Panel Mount |
| Protection Rating | IP20 |
| Operating Temperature | -20°C to 65°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Maximum Power Consumption | Approx. 11 W |
| Certifications | UL, CE, CSA, KC |
| Lifecycle Status | Active |
| Actual Dimensions (H × W × D) | 90 × 175 × 87 mm |
| Actual Weight | Approx. 0.62 kg |
| Typical Applications | Packaging Machines, Conveyor Systems, OEM Equipment, Pump Control, Small Machine Automation |
FAQ
FAQ
Q1: What is the Allen-Bradley 2080-LC50-24QWB used for?
A1: The 2080-LC50-24QWB is a Micro850 programmable controller used for compact industrial automation and OEM machine control applications.
Q2: How many onboard I/O points does the 2080-LC50-24QWB provide?
A2: The controller includes 24 embedded I/O points consisting of 14 digital inputs, 4 analog inputs, and 10 relay outputs.
Q3: Does the 2080-LC50-24QWB support Ethernet communication?
A3: Yes. The controller includes an embedded EtherNet/IP port supporting industrial Ethernet communication and Modbus TCP.
Q4: What type of outputs are included in the 2080-LC50-24QWB?
A4: The controller provides 10 relay outputs for controlling industrial loads and field devices.
Q5: Which software is used to program the 2080-LC50-24QWB?
A5: The controller is programmed using Connected Components Workbench (CCW) software.
Q6: What are the actual dimensions of the 2080-LC50-24QWB?
A6: The controller dimensions are 90 × 175 × 87 mm (H × W × D).
Q7: What is the actual weight of the 2080-LC50-24QWB?
A7: The approximate weight is 0.62 kg.
Q8: What are common applications for the 2080-LC50-24QWB?
A8: Common applications include conveyor automation, packaging equipment, pump systems, material handling, and general OEM industrial machinery.
