Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Allen-Bradley Ultra 3000 High-Voltage Digital Servo Drive |
| Model Number | 2098-DSD-HV100-SE |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Ultra 3000 |
| Product Type | Digital Servo Drive |
| Drive Type | High-Voltage SERCOS Servo Drive |
| Input Voltage | 230–480V AC Three-Phase |
| Input Frequency | 47–63 Hz |
| Continuous Output Power | Up to ~10 kW (system dependent) |
| Output Current | ~23 A continuous / up to ~46 A peak (variant dependent) |
| Communication Interface | SERCOS fiber-optic |
| Control Architecture | Digital servo control loop |
| Feedback Support | Encoder / high-resolution feedback systems |
| Safe Torque-Off | Not integrated (Ultra 3000 family dependent) |
| Shunt Regulator | Integrated for regenerative energy |
| Cooling Method | Forced air cooling |
| Mounting Type | Panel mount |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5–95% non-condensing |
| Certifications | CE, UL, CSA |
| Dimensions | Approx. 362 × 244 × 91 mm |
| Weight | Approx. 9–10 kg |
| Lifecycle Status | Discontinued (Ultra 3000 family) |
| Replacement Option | Kinetix 5700 / Kinetix 6000 migration path |
| Application | High-power multi-axis servo motion control systems |
FAQ
FAQ
Q1: What is the Allen-Bradley 2098-DSD-HV100-SE used for?
The 2098-DSD-HV100-SE is an Ultra 3000 high-voltage servo drive designed for precise multi-axis motion control in industrial automation systems such as packaging, robotics, and material handling.
Q2: What communication method does the 2098-DSD-HV100-SE use?
It uses a SERCOS fiber-optic communication interface for high-speed synchronized motion control.
Q3: What is the power rating of this drive?
The drive supports up to approximately 10 kW output power depending on system configuration and operating conditions.
Q4: What input power does the 2098-DSD-HV100-SE require?
It operates on a 230–480V AC three-phase industrial power supply.
Q5: Is the 2098-DSD-HV100-SE still manufactured?
No, it belongs to the discontinued Ultra 3000 series, which has been replaced by newer Kinetix servo drive platforms.
Q6: What is the output current capability?
It typically provides around 23 A continuous output current with higher peak capability depending on configuration.
Q7: What are the dimensions and weight of the unit?
The drive is approximately 362 × 244 × 91 mm and weighs about 9–10 kg.
Q8: What applications commonly use this drive?
It is commonly used in synchronized industrial motion systems such as packaging machines, conveyors, robotics, and coordinated servo positioning systems.
