Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Kinetix 5700 |
| Model Number | 2198-P070 |
| Product Type | DC-bus Power Supply Module |
| Module Function | Servo Drive Power Supply |
| Compatible Drives | Kinetix 5700 Servo Drives |
| Input Voltage | 324…528V AC |
| Nominal Voltage Class | 400V Class |
| Input Phase | 3-Phase |
| Input Frequency | 47…63 Hz |
| Continuous Output Power | 70 kW |
| Continuous Output Current | Approx. 104 A DC Bus |
| Regeneration Capability | Supports Shared Bus Regeneration |
| Integrated Shunt | No Internal Shunt Resistor |
| Communication Support | EtherNet/IP System Integration |
| Cooling Method | Forced Air Cooling |
| Mounting Type | Panel Mount |
| Protection Rating | IP20 |
| Status Indicators | Module Status LEDs |
| Overvoltage Protection | Yes |
| Short-circuit Protection | Yes |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Certifications | UL, CE, KC, RCM |
| Lifecycle Status | Active |
| Actual Dimensions (H × W × D) | Approx. 355 × 110 × 196 mm |
| Actual Weight | Approx. 7.2 kg |
| Typical Applications | Multi-axis Motion Control, Robotics, Packaging Machinery, Servo Power Distribution |
FAQ
FAQ
Q1: What is the Allen-Bradley 2198-P070 used for?
A1: The 2198-P070 is a Kinetix 5700 DC-bus power supply module used to provide shared bus power for Kinetix servo drive systems.
Q2: Which drives are compatible with the 2198-P070?
A2: The module is designed for use with Allen-Bradley Kinetix 5700 servo drive systems.
Q3: What input voltage does the 2198-P070 require?
A3: The module operates with 324…528V AC three-phase input power.
Q4: What is the output power rating of the 2198-P070?
A4: The module provides approximately 70 kW continuous DC-bus output power.
Q5: Does the 2198-P070 include an internal shunt resistor?
A5: No. The module does not include an internal shunt resistor and may require external regeneration hardware depending on the application.
Q6: What are the actual dimensions of the 2198-P070?
A6: The approximate dimensions are 355 × 110 × 196 mm (H × W × D).
Q7: What is the actual weight of the 2198-P070?
A7: The approximate weight is 7.2 kg.
Q8: What are common applications for the 2198-P070?
A8: Common applications include robotics, packaging machinery, automated assembly systems, coordinated multi-axis servo systems, and industrial motion control platforms.
