Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | PowerFlex 4 |
| Model Number | 22A-A2P3N114 |
| Product Type | AC Variable Frequency Drive (VFD) |
| Drive Function | Adjustable Frequency AC Motor Drive |
| Input Voltage | 100…120V AC |
| Nominal Voltage Class | 120V Class |
| Input Phase | 1-Phase |
| Output Voltage | 0…230V AC |
| Output Phase | 3-Phase |
| Rated Output Current | 2.3 A |
| Power Rating | 0.4 kW / 0.5 HP |
| Input Frequency | 48…63 Hz |
| Output Frequency Range | 0…400 Hz |
| Enclosure Rating | IP20 / NEMA Open Type |
| Integrated Keypad | Yes |
| Communication Interface | RS-485 (DSI Protocol) |
| Control Methods | V/Hz Control, Sensorless Vector Control |
| Embedded Brake Transistor | Yes |
| EMC Filter | No |
| Cooling Method | Natural / Forced Air Cooling |
| Mounting Type | DIN Rail or Panel Mount |
| Protection Features | Overcurrent, Overvoltage, Undervoltage, Overtemperature |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 0% to 95% Non-Condensing |
| Certifications | UL, CE, cUL |
| Lifecycle Status | Active / Mature |
| Actual Dimensions (H × W × D) | Approx. 150 × 72 × 136 mm |
| Actual Weight | Approx. 1.1 kg |
| Typical Applications | Small Conveyors, Fans, Pumps, Mixers, OEM Equipment |
FAQ
FAQ
Q1: What is the Allen-Bradley 22A-A2P3N114 used for?
A1: The 22A-A2P3N114 is a PowerFlex 4 AC drive used for controlling small three-phase AC motors in industrial and OEM applications.
Q2: What is the power rating of the 22A-A2P3N114?
A2: The drive is rated at 0.4 kW (0.5 HP).
Q3: What input power does the 22A-A2P3N114 require?
A3: The drive operates on 100…120V AC single-phase input power.
Q4: What is the rated output current of the 22A-A2P3N114?
A4: The drive provides 2.3 A rated output current.
Q5: Does the 22A-A2P3N114 include an integrated brake transistor?
A5: Yes. The drive includes a built-in dynamic brake transistor.
Q6: What communication interface is available on the 22A-A2P3N114?
A6: The drive includes an RS-485 communication port using the DSI protocol.
Q7: What are the actual dimensions and weight of the 22A-A2P3N114?
A7: The approximate dimensions are 150 × 72 × 136 mm (H × W × D) and the approximate weight is 1.1 kg.
Q8: What are common applications for the 22A-A2P3N114?
A8: Common applications include conveyors, small pumps, fans, mixers, packaging equipment, and OEM machinery.
