Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Allen-Bradley Compact 5000 I/O Terminal Block Kit |
| Model Number | 5069-RTB64-SCREW |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Compact 5000 (5069 I/O Platform) |
| Product Type | High-Density Removable Terminal Block (Screw Type) |
| Number of Positions | 64 positions |
| Signal Capacity | Typically supports 32 I/O signals + power/commons (module dependent) |
| Compatible Modules | 5069-IB32, 5069-OB32 and other high-density Compact 5000 modules |
| Wiring Type | Screw-clamp terminals |
| Wire Range | Approx. 22–12 AWG (0.34–3.3 mm²) |
| Rated Voltage | Up to 300V AC/DC (system dependent) |
| Rated Current | Approx. 10 A per terminal (typical specification) |
| Torque Specification | Approx. 0.56–0.79 N·m |
| Mounting Type | Direct mount to Compact 5000 I/O modules |
| Installation Style | Removable plug-in terminal block system |
| Protection Rating | IP20 (installed inside enclosure) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5–95% non-condensing |
| Dimensions | Approx. 138 × 22 × 105 mm |
| Weight | Approx. 0.05–0.20 kg |
| Application | Field wiring termination for high-density PLC I/O systems |
FAQ
FAQ
Q1: What is the Allen-Bradley 5069-RTB64-SCREW used for?
The 5069-RTB64-SCREW is a high-density removable terminal block used to connect field wiring to Compact 5000 I/O modules in CompactLogix and GuardLogix systems.
Q2: Why does the 5069 system need a 64-point RTB?
High-channel modules (such as 32-point I/O modules) require higher-density termination, and this RTB provides grouped wiring for both signals and power distribution.
Q3: Which modules are compatible with the 5069-RTB64-SCREW?
It is typically used with high-density modules like 5069-IB32 and 5069-OB32 series, depending on system configuration.
Q4: Is this RTB powered or active?
No, it is a passive component that only provides electrical connection between field wiring and I/O modules.
Q5: What type of wiring does it support?
It supports standard industrial copper wiring, typically in the 22–12 AWG range depending on installation requirements.
Q6: Can this terminal block be reused?
Yes, it is removable and reusable when replacing or servicing Compact 5000 I/O modules.
Q7: What is the main advantage of using the 5069-RTB64-SCREW?
It simplifies dense wiring layouts by consolidating multiple I/O points into a single structured termination interface.
Q8: What happens if the wrong RTB is installed?
Using an incorrect RTB can lead to miswiring, module damage, or inability to properly seat the I/O module in the backplane system.
