Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | ProSoft inRAx Communication Module |
| Model Number | MVI69-DFNT |
| Product Type | DF1 to EtherNet/IP Gateway Module |
| Platform Compatibility | Allen-Bradley CompactLogix / MicroLogix (1769 backplane) |
| Function | Converts DF1 serial protocol to EtherNet/IP communication |
| Protocol Support | DF1 (Full Duplex / Half Duplex), EtherNet/IP |
| Ethernet Port | 1 × 10/100 Mbps RJ45 |
| Serial Ports | 1 × DF1 serial port (RS-232/422/485 configurable) |
| Slot Requirement | Single-slot 1769 I/O module |
| Data Transfer Method | Internal database mapping to PLC tags |
| Configuration Method | Web-based configuration + Add-On Instruction (AOI) |
| Network Features | CIP messaging support, Ethernet diagnostics |
| Backplane Current | Approx. 800 mA @ 5 VDC |
| Isolation | Electrical isolation between ports and backplane |
| Diagnostics | LED indicators + embedded web server diagnostics |
| Mounting Type | CompactLogix rack-mounted module |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | Approx. 137 × 87 × 105 mm |
| Weight | Approx. 0.5–1.2 kg |
FAQ
FAQ
Q1. What is the MVI69-DFNT used for?
It is used to connect DF1 serial devices to EtherNet/IP networks through a CompactLogix PLC.
Q2. What protocols does it convert?
It converts DF1 serial communication to EtherNet/IP.
Q3. What PLC platforms support this module?
It is designed for CompactLogix and some MicroLogix systems using the 1769 backplane.
Q4. How is it configured?
It is configured through a web interface and integrated into Studio 5000 using an Add-On Instruction.
Q5. What is the main advantage of this module?
It allows legacy serial devices to communicate on modern Ethernet/IP networks.
Q6. Does it support both DF1 modes?
Yes, it supports both Full Duplex and Half Duplex DF1 communication.
Q7. How does data exchange work with the PLC?
Data is mapped into an internal database and accessed as PLC tags.
Q8. What is the weight of the module?
Approximately 0.5–1.2 kg, depending on configuration and packaging.
