Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | 330101-00-10-10-12-05 |
| Probe Tip Diameter | 8.0 mm |
| Probe Case Material | Stainless Steel (AISI 303/304) |
| Probe Tip Material | PPS |
| Cable Type | 75Ω triaxial FEP-insulated |
| Connector Type | Miniature coaxial ClickLoc with FluidLoc cable |
| Cable Length (Total) | 1.0 meter |
| Recommended Gap | 1.27 mm (50 mils) |
| Linear Range | 0.25 mm to 2.3 mm |
| Output Sensitivity | 7.87 V/mm ±5% |
| Frequency Response | 0–10 kHz |
| Operating Temperature (Probe) | -52°C to +177°C |
| Operating Temperature (Cable) | -52°C to +177°C |
| Minimum Target Diameter | 15.2 mm |
| Minimum Shaft Diameter | 50.8 mm |
| Weight | 0.323 kg |
| Total Length | 1.0 meter |
FAQ
FAQ
Q1: What environments is this probe suitable for?
A1: It is rated for -52°C to +177°C and high-humidity conditions, ideal for harsh industrial environments.
Q2: Does the cable prevent oil leakage?
A2: Yes, this model uses a FluidLoc cable to effectively prevent oil leakage through the cable interior.
Q3: What is the recommended gap setting?
A3: The recommended gap between the probe tip and target is 1.27 mm (50 mils).
Q4: What is the output sensitivity of the probe?
A4: The output sensitivity is 7.87 V/mm with a tolerance of ±5%.
Q5: What is the linear measurement range?
A5: The linear range is 0.25 mm to 2.3 mm.
Q6: Are special tools required to install the connectors?
A6: No, the ClickLoc connectors are designed for hand-tight installation without tools.
Q7: What shaft diameters is the probe suitable for?
A7: It is recommended for shafts with a diameter of at least 50.8 mm.
Q8: Is there a minimum bend radius for the cable?
A8: Yes, the minimum bend radius is 25.4 mm to avoid damaging the cable.
