Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 330101-00-79-15-02-05 |
| Probe Tip Diameter | 8.0 mm (0.31 in) |
| Thread Size | 3/8-24 UNF |
| Probe Case Material | AISI 303 or 304 Stainless Steel |
| Probe Cable Type | 75Ω triaxial, FEP insulated |
| Connector Type | Miniature coaxial ClickLoc, gold-plated |
| Cable Length | 1.5 meters |
| Linear Range | 2 mm (80 mils), typically from 0.25 mm to 2.3 mm |
| Recommended Gap | -9 VDC, approx. 1.27 mm (50 mils) |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) ± 5% (5 m system) |
| Output Resistance | 50 Ω |
| Temperature Range (Standard Probe) | -52°C to +177°C (-62°F to +350°F) |
| Minimum Shaft Diameter | 50.8 mm (2 in) |
| Minimum Target Size | 15.2 mm (0.6 in) diameter (flat surface) |
| Probe Pressure Seal | Viton® O-ring |
| Frequency Response | 0 to 10 kHz, +0/-3 dB with up to 305 m field wiring |
| EMC Compliance | EN 61000-6-2, EN 61000-6-4 |
| Hazardous Area Ratings | ATEX, IECEx, cNRTLus, SIL2/SIL3 capable |
| Environmental Protection | IP54 or better (with proper installation) |
| Minimum Cable Bend Radius | 25.4 mm (1.0 in) |
| Weight | 0.485 kg (total) |
| Total Length | 1.5 meters |
FAQ
FAQ
Q1: Does this probe comply with API 670 standards?
A1: Yes, the Bently Nevada 3300 XL 8 mm Proximity Probe meets API 670 requirements for mechanical design, linearity, and accuracy.
Q2: Are special tools required for installation?
A2: No, the ClickLoc connectors are designed for tool-free, finger-tight installation.
Q3: What temperature range can this probe operate in?
A3: The standard probe operates from -52°C to +177°C, and the extended version supports up to +218°C.
Q4: Is this probe compatible with older Proximitor sensors?
A4: Yes, it is fully backward compatible with non-XL 3300 5 mm and 8 mm systems.
Q5: Does the cable include oil leakage protection?
A5: Yes, the optional FluidLoc cable prevents oil or liquid from leaking through the cable.
Q6: Is it suitable for high-density installations?
A6: Yes, the Proximitor sensor supports both DIN rail and panel mounting for dense installations.
Q7: How does it perform in environments with electromagnetic interference?
A7: It has enhanced RFI/EMI immunity and meets CE compliance without requiring shielded conduit.
Q8: Is the probe sealed for pressure applications?
A8: Yes, the probe features a Viton® O-ring seal designed for pressure isolation between tip and case.
