Technical Specifications
| Parameter | Specification |
|---|---|
| Probe Tip Diameter | 8 mm |
| Thread Size | M10 x 1 |
| Cable Type | 75Ω triaxial, FEP insulated |
| Total Length | 1.0 meter |
| Weight | 0.323 kg |
| Operating Temperature | -52°C to +177°C (standard) |
| Extended Temp (optional) | up to +218°C (probe tip), +260°C (cable) |
| Linear Range | 2 mm (80 mils) |
| Recommended Gap | ~1.27 mm (50 mils) |
| Material (Probe Case) | Stainless Steel 303/304 |
| Connector | Gold-plated ClickLoc coaxial |
| Minimum Shaft Diameter | 50.8 mm recommended, ≥76.2 mm optimal |
| Frequency Response | 0–10 kHz (+0, -3 dB) |
| Humidity Resistance | <3% ASF change at 93% RH |
FAQ
FAQ
Q1: What is the thread size of this probe?
A1: The probe has a metric M10 x 1 thread.
Q2: What is the recommended gap setting?
A2: The recommended gap is approximately 1.27 mm (50 mils).
Q3: What is the operating temperature range?
A3: Standard range is -52°C to +177°C, with optional high-temperature versions up to +218°C.
Q4: What is the minimum shaft diameter for use?
A4: Recommended minimum shaft diameter is 50.8 mm, optimal at 76.2 mm or larger.
Q5: What type of cable is used in the probe?
A5: The probe uses a 75Ω triaxial FEP insulated cable.
Q6: What is the weight of the probe?
A6: At 1 meter total length, the weight is approximately 0.323 kg.
Q7: What is the linear measurement range?
A7: The linear range is 2 mm (80 mils).
Q8: Are special tools required for installation?
A8: No, the ClickLoc connector is designed for finger-tight installation without tools.
