Technical Specifications
| Parameter | Specification |
|---|---|
| Sensor Head Diameter | 25.4 mm |
| Weight (Typ.) | 0.715 kg (for 2.5 m version) |
| Sensitivity | 5.7 mV/mm/s (145 mV/in/s) ±5% |
| Frequency Response | 15–2000 Hz (±3.0 dB); 20–1000 Hz (±0.9 dB) |
| Amplitude Range | 635 mm/s peak (<680 Hz); 2940 m/s² peak (>680 Hz) |
| Amplitude Linearity | ±2% to 152 mm/s peak |
| Mounted Resonant Freq. | >5 kHz |
| Output Bias Voltage | -12 ±2.0 VDC |
| Noise Floor (15Hz–2kHz) | 0.127 mm/s RMS (nominal) |
| Transverse Sensitivity | <5% of sensitivity |
| Max Cable Length | 305 m |
| Operating Temp (Sensor) | -55°C to +400°C |
| Operating Temp (Cable) | -55°C to +400°C |
| Operating Temp (Electronics) | -55°C to +121°C |
| Humidity Resistance | 100%, non-submerged, hermetically sealed |
| Shock Survivability | 24,535 m/s² (2500 g) peak |
| Case Material | 300 series stainless steel |
| Connector | 2-pin Mil-C-5015 hermetically-sealed |
| Minimum Bend Radius | 51 mm (2.0 in) |
| Polarity | Pin A is positive when velocity is from base to top |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the maximum temperature the 330752 sensor can withstand?
A1: The sensor head and cable can operate in environments up to +400°C.
Q2: What is the primary application of the 330752-25-05 sensor?
A2: It is used for vibration monitoring in high-temperature industrial environments.
Q3: What is the standard sensitivity rating?
A3: The sensor has a sensitivity of 5.7 mV/mm/s (145 mV/in/s) ±5%.
Q4: Is the sensor suitable for Zone 0 hazardous areas?
A4: Yes, it has intrinsic safety certifications for use in Zone 0 and Zone 2 environments.
Q5: Can the integrated cable be replaced?
A5: No, the cable is permanently attached to avoid connection failures.
Q6: How long can the signal cable be without loss?
A6: Up to 305 meters (1000 feet) without signal degradation.
Q7: What is the impact of incorrect mounting?
A7: Incorrect mounting may reduce frequency response and generate false signals.
Q8: Is the sensor waterproof?
A8: It is hermetically sealed and resistant to 100% humidity, but not designed for submersion.
