Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | KJ4003X1-BD1 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ VerticalPlus |
| Product Type | 4-Wide VerticalPlus SISNet Repeater Carrier |
| Application | DeltaV Distributed Control System (DCS) |
| System Function | SISNet communication repeater / signal routing |
| LocalBus Power | 12.6 VDC at 15 A |
| Maximum Network Length | Up to 6.5 m (LocalBus + extender total limit) |
| Operating Temperature | -40°C to +70°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Shock Resistance | 10 g, ½ sine wave for 11 ms |
| Vibration Resistance | 1 mm peak-to-peak (2–13.2 Hz); 0.7 g (13.2–150 Hz) |
| Airborne Contaminant Rating | ISA-S71.04-1985 Class G3 |
| Protection Rating | IP20 |
| Hazardous Area Approval | Class I, Division 2 / Zone 2 (Ex ec IIC Gc) |
| Mounting Type | Cabinet / Rack Mount |
| Maintenance | No user-serviceable parts |
| Calibration | Not required |
| Dimensions (L × W × H) | Approximately 150 mm × 220 mm × 30 mm |
| Weight | Approximately 0.35 kg |
FAQ
FAQ
Q1: What is the Emerson KJ4003X1-BD1 used for?
It is a SISNet Repeater Carrier used in DeltaV VerticalPlus systems to support communication and signal routing between system segments.
Q2: What is the main function of this module in a DeltaV system?
It provides communication continuity and signal extension for SISNet-based architecture within the control system.
Q3: What is the operating voltage of the KJ4003X1-BD1?
It operates on a LocalBus power supply of 12.6 VDC at up to 15 A.
Q4: What are the physical dimensions of the KJ4003X1-BD1?
The unit is approximately 150 mm × 220 mm × 30 mm in size.
Q5: What is the weight of the KJ4003X1-BD1?
The approximate weight is 0.35 kg.
Q6: Can the KJ4003X1-BD1 be used in hazardous environments?
Yes, it is certified for Class I Division 2 and Zone 2 hazardous locations when installed according to Emerson guidelines.
Q7: What environmental conditions can it handle?
It supports -40°C to +70°C operating temperature and 5%–95% non-condensing humidity.
Q8: Does the module require maintenance or calibration?
No, it has no user-serviceable parts and does not require calibration during its lifecycle.
