Technical Specifications
| Parameter | Description |
|---|---|
| Sensor Type | Eddy Current Non-Contact Displacement Sensor |
| Probe Diameter | 8 mm |
| Linear Measuring Range | 2 mm (Standard), up to 4 mm or 8 mm (with appropriate converter version) |
| Initial Gap | 0.5 mm |
| Incremental Scale Factor | 8 V/mm ±5% (0 to 45°C) |
| Linearity Error (DSL) | ±0.025 mm (±1 mil) |
| Target Material | 42CrMo4 (AISI/SAE 4140) standard; others on request |
| Minimum Shaft Diameter | 25 mm |
| Operating Temperature | -35°C to +180°C (Sensor with 1m Cable) |
| Cable & Connector Temp. | -35°C to +150°C |
| Protection Rating | IP66 (Sensor), IP20 (Converter) |
| Sensor Materials | Tip: PEEK; Housing: Stainless Steel |
| Cable Materials | PTFE cable; Nickel-plated brass connector |
| Power Supply (CON021) | -23V to -32V (Output -4 to -20V) or -21V to -32V (Output -2 to -18V) |
| Frequency Response (-3 dB) | 0 – 20,000 Hz |
| Rise Time | < 15 µs |
| Weight | Sensor: approx. 0.22 kg; Converter: approx. 0.12 kg |
| Mounting Threads | M10x1 or 3/8″-24 UNF |
| Cable Diameter | Standard: 2.8 mm; Armored: 6.0 mm |
| Minimum Bending Radius | 25 mm (standard cable); 35 mm (armored cable) |
| Hazardous Area Approval | ATEX / IEC-Ex / CSA Intrinsic Safety (ia) & Non-sparking (nA) |
| Electrical Connection | Lemo connector (sensor), Screw terminal (converter supply/output) |
| Compatibility | Compatible with PR6422 / PR6423 / PR6424 / PR6425 / PR6426 sensors |
FAQ
FAQ
Q1: What type of machinery is this sensor suitable for?
A1: It is designed for critical rotating equipment like steam turbines, gas turbines, hydro turbines, compressors, gearboxes, pumps, and fans.
Q2: What is the maximum measuring range with the CON021 converter?
A2: The standard range is 2 mm; with extended CON021 versions, it can support up to 8 mm.
Q3: Can the probe withstand high-temperature environments?
A3: Yes, the PR6423 sensor can operate at temperatures up to +180°C.
Q4: Does this sensor have hazardous area certifications?
A4: Yes, it is certified under ATEX, IEC-Ex, and CSA for intrinsic safety and non-sparking use.
Q5: Is it possible to customize the cable length and mounting options?
A5: Yes, multiple cable lengths, thread types, and mounting styles including reverse mount are available.
Q6: What type of signal output does the sensor provide?
A6: It provides a voltage output, typically -2V to -18V or -4V to -20V depending on supply voltage.
Q7: How are electrical connections made?
A7: The sensor uses a self-locking LEMO connector; the converter uses screw terminals (up to 1.5 mm² wire).
Q8: Can PR6423 be used with other converter types?
A8: Yes, but optimal performance is achieved when paired with CON021 series converters.
