Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Foxboro (Schneider Electric / Invensys) |
| Model | FBM207 |
| Product Number | P0916PH |
| Current / Superseding Part Number | RH916PH |
| Product Type | Voltage Monitor Input Field Terminal Assembly |
| System | Foxboro I/A Series / Standard 200 Series |
| Input Channels | 16 |
| Input Type | AC Voltage Monitor |
| Rated Input Voltage | 240 VAC |
| Logic Zero | 0–40 VAC |
| Logic One | 160–280 VAC |
| Input Current at Logic One | 1.6 mA maximum |
| Channel Isolation | FBM207 channel isolation |
| Terminal Type | Compression terminals |
| Main Function | Provides field-wiring termination and signal connection for the FBM207 voltage-monitor inputs |
| Termination Cable | Type 4 |
| Mounting | DIN rail mounted |
| Housing Material | Polyamide (PA) |
| Operating Temperature | -20 to +70°C (-4 to +158°F) |
| Dimensions (L × W × H) | Approx. 125 × 80 × 72 mm |
| Approx. Weight | Approx. 0.35 kg |
| Origin | USA |
FAQ
FAQ
Q1: What is Foxboro FBM207 P0916PH?
A: It is a Voltage Monitor Input Field Terminal Assembly designed for the Foxboro FBM207 16-channel voltage-monitor input configuration.
Q2: Is P0916PH the electronic FBM207 module?
A: No. P0916PH is the Field Terminal Assembly. The FBM207 provides the electronic input monitoring and channel isolation.
Q3: How many channels does P0916PH support?
A: It provides field termination for 16 voltage-monitor input channels.
Q4: What input voltage is supported?
A: P0916PH is designed for 240 VAC voltage monitoring, with 0–40 VAC recognized as Logic Zero and 160–280 VAC recognized as Logic One.
Q5: What is the maximum input current at Logic One?
A: The specified input current at Logic One is 1.6 mA maximum.
Q6: What type of terminals does P0916PH use?
A: It uses compression terminals and is designed for DIN-rail mounting. The associated termination cable is Type 4.
Q7: What are the dimensions and weight of P0916PH?
A: The approximate dimensions are 125 × 80 × 72 mm (L × W × H), with an approximate weight of 0.35 kg. Foxboro’s dimensional data lists approximately 125 mm overall width and 72 mm height above the DIN rail.
Q8: Is P0916PH still the current part number?
A: P0916PH is the earlier part number. RH916PH is the newer/superseding compression termination assembly for the FBM207 240 VAC voltage-monitor application.
