Technical Specifications
| Parameter | Specification |
|---|---|
| Model | GE DS200TCTEG1ABA |
| Product Type | TC2000 Trip Module |
| System Series | GE Mark V Control System |
| Primary Function | Turbine trip and protection logic processing |
| Control Scope | Latching and interlock management |
| Input Type | Discrete trip contacts and logic inputs |
| Output Type | Trip relay drive outputs |
| Response Type | Real-time hardware-based logic |
| Operating Voltage | Supplied from Mark V backplane |
| Communication | Backplane data exchange with control processor |
| Diagnostic Features | Board status LEDs and system alarms |
| Redundancy Support | Designed for use in protected configurations |
| Mounting | Control cabinet / rack installation |
| Connector Type | Multi-pin edge connectors |
| Environmental Rating | Industrial control environment |
| Dimensions (W × H × D) | 200 × 120 × 35 mm |
| Weight | 0.82 kg |
FAQ
FAQ
Q1: What is the main function of the DS200TCTEG1ABA?
A1: It processes turbine trip logic and ensures safe shutdown when abnormal conditions occur.
Q2: Does this module directly control the trip solenoids?
A2: It provides the logic and output drive signals that interface with downstream trip devices.
Q3: Can this board operate independently from the main controller?
A3: No, it works as part of the Mark V system architecture and depends on the control processor.
Q4: Is programming required for this module?
A4: Trip logic is defined at system level; the board itself does not require field programming.
Q5: How does the board indicate a fault condition?
A5: Through onboard indicators and system alarms communicated to the control processor.
Q6: Can it be hot-swapped during operation?
A6: No, power should be isolated before installing or removing the module.
Q7: Is it used in both gas and steam turbine systems?
A7: Yes, it is applied in various turbine control environments where Mark V is used.
Q8: What should be checked if nuisance trips occur?
A8: Verify field wiring, input signals, grounding quality, and power stability.
