GE Fanuc IC695SPF550 Small Form Factor Pluggable Transceiver

FAQ

Q1: What is the main purpose of the GE Fanuc IC695SPF550 module?
A1: The IC695SPF550 is an SFP transceiver used to provide optical fiber connectivity for RX3i Ethernet modules, enabling high-speed communication up to 1.25 Gbps.

Q2: What type of fiber does this transceiver support?
A2: It supports multimode fiber (MMF) with an LC duplex connector.

Q3: What is the maximum transmission distance?
A3: The module supports transmission distances of up to 550 meters.

Q4: What wavelength does the IC695SPF550 operate at?
A4: It operates at a wavelength of 850 nm.

Q5: Is the IC695SPF550 hot-swappable?
A5: Yes, the module supports hot-swapping, allowing it to be replaced without shutting down the system.

Q6: What standards does the module comply with?
A6: It complies with IEEE 802.3z 1000BASE-SX and SFP MSA standards.

Q7: Does it support diagnostic monitoring?
A7: Yes, it features Digital Diagnostics Monitoring (DDM) to track parameters such as temperature, voltage, and optical power.

Q8: What is the operating temperature range of this transceiver?
A8: The operating temperature range is 0°C to 70°C.
