Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | GE Fanuc (now Emerson Automation Solutions) |
| Product Model | IC200ALG326H |
| Product Type | Analog Current Output Module |
| Series | VersaMax I/O |
| Output Type | Analog Current Output (Current Sourcing) |
| Number of Output Channels | 8 single-ended channels |
| Output Range | 4–20 mA (default) / 0–20 mA (jumper configurable) |
| Resolution | 13-bit (approximately 2.5 μA/count) |
| Output Accuracy (25°C) | ±0.3% typical of full scale; ±0.5% maximum of full scale |
| Full Scale Output Current | Approximately 20.38 mA including overrange capability |
| Update Rate | 15 ms maximum |
| Output Load | External load required; current sourcing output |
| External Power Supply | 18–30 VDC including ripple |
| Field Power Consumption | 100 mA maximum (no load); 185 mA maximum (all outputs full scale) |
| Inrush Current | 2 A maximum |
| Backplane Current Consumption | 50 mA maximum at 5 VDC |
| Isolation | 250 VAC continuous; 1500 VAC for 1 minute |
| Output Configuration | One group of 8 outputs |
| LED Indicators | FLD PWR LED (field power status); OK LED (backplane power status) |
| Mounting Type | VersaMax Carrier Base Mount |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (W × H × D) | 50 × 110 × 66.8 mm |
| Weight | Approx. 0.20 kg |
| Application | Valve position control, actuator control, variable speed drive reference signals, industrial process control |
| Revision | H |
| Condition | New and Original |
| Warranty | 12 months |
FAQ
FAQ
Q1: What is the GE IC200ALG326H used for?
The IC200ALG326H is used in VersaMax PLC systems to generate analog current control signals for field devices such as control valves, actuators, positioners, and drive controllers.
Q2: How many analog output channels does the IC200ALG326H provide?
The module provides 8 single-ended analog current output channels.
Q3: What output signals are supported by the IC200ALG326H?
The module supports 4–20 mA output signals as the default configuration and can be configured for 0–20 mA operation using a jumper setting.
Q4: What is the resolution of the IC200ALG326H?
The module provides approximately 13-bit analog output resolution, with about 2.5 μA per count.
Q5: Does the IC200ALG326H require an external power supply?
Yes. The analog outputs require an external 18–30 VDC field power supply to drive connected loads.
Q6: What are the dimensions and weight of the IC200ALG326H?
The module has approximate dimensions of 50 × 110 × 66.8 mm and weighs about 0.20 kg.
Q7: What diagnostic features are available?
The module includes an OK LED indicating backplane power status and a FLD PWR LED indicating the presence of external field power.
Q8: What are the advantages of the GE IC200ALG326H?
The IC200ALG326H provides high-density analog current outputs, standard 4–20 mA compatibility, reliable isolation, fast update performance, compact VersaMax design, and suitability for industrial process control applications.
