Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE Fanuc (now Emerson Automation) |
| Product Model | IC200MDD845G |
| Product Type | Discrete Mixed I/O Module |
| Series | VersaMax I/O |
| Function | Combines digital DC inputs and relay outputs in a single VersaMax module |
| Number of I/O Points | 24 points total |
| Input Points | 16 points |
| Output Points | 8 points |
| Input Type | 24 VDC Positive Logic Input |
| Input Groups | 2 groups of 8 inputs |
| Nominal Input Voltage | 24 VDC |
| Input Voltage Range | 18–30 VDC |
| ON-State Voltage | 15–30 VDC |
| OFF-State Voltage | 0–5 VDC |
| ON-State Current | 2.0–5.5 mA |
| OFF-State Current | 0–0.5 mA |
| Input Impedance | 10 kΩ maximum |
| Output Type | Form A (Normally Open) Relay Contact Output |
| Output Points | 8 isolated relay outputs |
| Output Contact Rating | 2.0 A maximum for 5–265 VAC resistive load |
| DC Output Rating | 2.0 A maximum for 5–30 VDC resistive load |
| DC Output Rating (Higher Voltage) | 0.2 A maximum for 31–125 VDC resistive load |
| Output Voltage Range | 0–265 VAC / 0–125 VDC |
| Output Isolation | Individual channel isolation between relay outputs |
| Input/Output Response Time | 0.5 ms ON / 10 ms OFF typical |
| Protection | No internal fuses or surge suppression |
| External Power Supply | Required for field-side loads |
| Backplane Current Consumption | 270 mA maximum @ 5 VDC |
| LED Indicators | Individual I/O status LEDs and OK LED |
| Module ID | 80088040 |
| Compatible Carrier Bases | IC200CHS series VersaMax carriers |
| Mounting Method | DIN rail mounting |
| Compatible Systems | GE Fanuc / Emerson VersaMax PLC and Distributed I/O |
| Operating Temperature | 0°C to +60°C (32°F to +140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5–95% RH (non-condensing) |
| Dimensions (H × W × D) | Approx. 110 × 66.8 × 50 mm (4.33 × 2.63 × 1.97 in.) |
| Weight | Approx. 0.28 kg (0.63 lb) |
| Hardware Revision | G |
| Product Status | Legacy Product |
| Warranty | 12 Months |
FAQ
FAQ
Q1: What is the GE Fanuc IC200MDD845G used for?
The IC200MDD845G is used in VersaMax PLC systems to collect 24 VDC digital input signals and control external devices through relay outputs. Typical applications include machine control, motor control, valve control, and industrial automation equipment.
Q2: How many input and output channels does the IC200MDD845G provide?
The module provides 24 total I/O points, including 16 digital inputs and 8 relay outputs.
Q3: What type of input signals does the IC200MDD845G support?
The input section supports 24 VDC positive logic inputs with an operating range of approximately 18–30 VDC. It can be connected to switches, sensors, proximity devices, and other DC field devices.
Q4: What type of outputs are available on the IC200MDD845G?
The module provides 8 Form A normally open relay contact outputs. Each relay output is individually isolated and can switch AC or DC loads within the specified ratings.
Q5: What is the maximum load current of the relay outputs?
Each relay output can handle up to 2.0 A for 5–265 VAC resistive loads and 2.0 A for 5–30 VDC resistive loads. For 31–125 VDC applications, the maximum current is reduced to 0.2 A.
Q6: Does the IC200MDD845G require an external power supply?
Yes. The module receives logic power from the VersaMax backplane, but an external field power supply is required for connected input devices and relay-controlled loads.
Q7: What is the difference between the IC200MDD845G and standard discrete modules?
The IC200MDD845G combines both input and output functions in one module, reducing rack space requirements compared with using separate input and output modules. It also provides isolated relay outputs for controlling higher-power devices.
Q8: What should be checked before replacing an IC200MDD845G module?
Before replacement, verify the VersaMax carrier compatibility, input voltage level, relay output load ratings, field wiring connections, external power supply, module addressing, and PLC configuration to ensure proper operation after installation.
