Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | GE Fanuc (now Emerson Automation Solutions) |
| Product Model | IC200MDL241B |
| Product Type | AC Discrete Input Module |
| Series | VersaMax I/O |
| Input Type | Positive Logic (Sourcing) AC Input |
| Number of Input Points | 16 |
| Input Groups | 2 groups of 8 inputs |
| Nominal Input Voltage | 240 VAC |
| Input Voltage Range | 0–264 VAC |
| Input Frequency | 47–63 Hz |
| Logic Type | Positive Logic (Sourcing) |
| Response Time (ON) | 1 AC cycle maximum |
| Response Time (OFF) | 2 AC cycles maximum |
| Isolation | 250 VAC continuous (field to logic and frame ground), 1500 VAC for 1 minute |
| Backplane Power | Powered by VersaMax backplane |
| LED Indicators | One green LED per input point and one OK status LED |
| Input Configuration | Two isolated groups of eight inputs |
| External Field Power | Required (AC input signals) |
| Mounting Type | VersaMax Carrier Base |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Hazardous Area Rating | Class I, Division 2 (when installed according to manufacturer guidelines) |
| Dimensions (W × H × D) | 50 × 110 × 67 mm |
| Weight | 0.20 kg |
| Application | PLC AC signal monitoring, machine automation, process control, and industrial equipment |
| Condition | New and Original |
| Warranty | 12 months |
FAQ
FAQ
Q1: What is the GE IC200MDL241B used for?
The IC200MDL241B is used to acquire 240 VAC digital input signals from field devices such as pushbuttons, selector switches, limit switches, relay contacts, and auxiliary contacts in VersaMax PLC systems.
Q2: How many input channels does the IC200MDL241B provide?
The module provides 16 AC input channels, organized into two groups of eight inputs, allowing flexible field wiring and monitoring.
Q3: What input voltage does the IC200MDL241B support?
It is designed for a 240 VAC nominal input and supports an operating voltage range of 0–264 VAC at 47–63 Hz.
Q4: What are the dimensions and weight of the IC200MDL241B?
The module measures approximately 50 × 110 × 67 mm and weighs approximately 0.20 kg.
Q5: Does the IC200MDL241B require an external power supply?
Yes. The connected field devices require an external AC power source, while the module itself receives operating power from the VersaMax backplane.
Q6: What isolation protection does the module provide?
The IC200MDL241B provides 250 VAC continuous isolation between field wiring and logic circuitry, with 1500 VAC dielectric withstand for one minute, improving electrical safety and system reliability.
Q7: What diagnostic features are included?
The module includes one LED for each input point to indicate channel status, along with an OK LED showing that backplane power and module operation are normal.
Q8: What are the advantages of the GE IC200MDL241B?
The IC200MDL241B offers reliable 240 VAC input monitoring, 16-channel capacity, fast AC response, high electrical isolation, individual LED diagnostics, compact VersaMax design, and dependable performance for industrial PLC and process automation applications.
