GE IC200PWR101E AC Power Supply Module

FAQ

Q1: What is the GE Fanuc IC200PWR101E used for?
The IC200PWR101E is an AC power supply module designed for the VersaMax PLC platform. It delivers regulated backplane power to CPUs, Network Interface Units (NIUs), and I/O modules, ensuring stable operation of the entire control system.

Q2: What input voltage does the IC200PWR101E support?
The module accepts 85–132 VAC for 120 VAC applications with the jumper installed, or 176–264 VAC for 240 VAC applications with the jumper removed. It operates at 47–63 Hz.

Q3: What output voltages are available?
The IC200PWR101E provides two regulated DC outputs: 5 VDC and 3.3 VDC. The combined maximum output current is 1.5 A, with the 3.3 VDC output limited to 0.25 A.

Q4: Can the IC200PWR101E be used as a secondary power supply?
Yes. Besides powering a VersaMax station directly, the module can be installed on a Power Supply Booster Carrier to provide supplemental backplane power for larger I/O configurations.

Q5: What protection features are built into the module?
The IC200PWR101E includes short-circuit protection and overload protection, helping safeguard both the power supply and connected VersaMax modules during abnormal operating conditions.

Q6: How is the input voltage configured?
A jumper is installed for 120 VAC operation. For 240 VAC operation, the jumper must be removed. Using the jumper with a 240 VAC input can damage the module.

Q7: What does the “E” revision indicate?
The “E” suffix identifies the hardware revision of the IC200PWR101 module. Revision E maintains the same electrical specifications and VersaMax compatibility while incorporating manufacturing and lifecycle improvements.

Q8: What should be checked before replacing an IC200PWR101E module?
Before replacement, verify the VersaMax CPU or NIU compatibility, AC input voltage selection, jumper position, total backplane power requirements, wiring integrity, and mounting location. Since the IC200PWR101 has been superseded by the IC200PWR102, compatibility should also be confirmed if using the newer replacement model.
