Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE Fanuc (now Emerson Automation) |
| Product Model | IC200UEX636-C |
| Product Type | Analog Expansion Unit |
| Series | VersaMax Micro PLC |
| Function | Expands VersaMax Micro PLC analog input and output capability |
| Power Supply Type | 120/240 VAC |
| Input Power Range | 85–264 VAC, 47–63 Hz |
| Number of Analog Inputs | 4 channels |
| Number of Analog Outputs | 2 channels |
| Analog Input Types | Voltage and current inputs |
| Analog Input Ranges | 0–10 VDC, ±10 VDC, 0–20 mA, 4–20 mA |
| Analog Output Types | Voltage and current outputs |
| Analog Output Ranges | 0–10 VDC, 0–20 mA, 4–20 mA |
| Resolution | 12-bit |
| Input Accuracy | Approximately ±0.1% of full scale |
| Output Accuracy | Approximately ±0.1% of full scale |
| Sensor Power Supply | 24 VDC user supply, 200 mA maximum |
| Input Impedance | Voltage input: High impedance; Current input: approximately 250 Ω |
| Conversion Method | Analog-to-digital and digital-to-analog conversion |
| Data Format | 12-bit digital values transferred to VersaMax Micro PLC |
| Expansion Capability | Supports connection of up to 4 analog expansion units |
| Communication Interface | VersaMax Micro expansion bus |
| Status Indicators | Module status LED |
| Isolation | Field I/O isolation from logic circuits |
| Input Power Rating | 15 VA maximum |
| Input Current | Approx. 0.06 A at 264 VAC |
| Inrush Current | 4 A maximum for 5 ms at 264 VAC |
| Hold-up Time | 223 ms minimum at 85 VAC |
| Mounting Method | DIN rail / panel mounting with VersaMax Micro system |
| Compatible Systems | GE Fanuc VersaMax Micro PLC |
| Operating Temperature | 0°C to +55°C (32°F to +131°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5–95% RH (non-condensing) |
| Dimensions (H × W × D) | Approx. 90 × 150 × 76 mm (3.54 × 5.91 × 2.99 in.) |
| Weight | Approx. 0.45 kg (0.99 lb) |
| Hardware Revision | C |
| Product Status | Legacy Product |
| Warranty | 12 Months |
FAQ
FAQ
Q1: What is the GE Fanuc IC200UEX636-C used for?
The IC200UEX636-C is used to expand the analog I/O capability of VersaMax Micro PLC systems. It allows the PLC to connect with analog sensors, transmitters, and control devices requiring voltage or current signals.
Q2: How many analog channels does the IC200UEX636-C provide?
The module provides 4 analog input channels and 2 analog output channels, allowing both signal measurement and analog device control.
Q3: What analog input signals are supported by the IC200UEX636-C?
The analog inputs support 0–10 VDC, ±10 VDC, 0–20 mA, and 4–20 mA signals, making the module suitable for industrial transmitters and measurement devices.
Q4: What analog output signals are supported by the IC200UEX636-C?
The module provides analog outputs supporting 0–10 VDC, 0–20 mA, and 4–20 mA ranges for controlling actuators, drives, valves, and other analog devices.
Q5: What power supply does the IC200UEX636-C require?
The IC200UEX636-C requires a 120/240 VAC power supply with an operating range of approximately 85–264 VAC.
Q6: What is the resolution of the IC200UEX636-C analog channels?
The module provides 12-bit analog resolution, allowing accurate conversion between analog signals and PLC digital values.
Q7: How many analog expansion units can be connected to a VersaMax Micro PLC?
A VersaMax Micro PLC system can support up to four analog expansion units, allowing additional analog input and output capacity.
Q8: What should be checked before replacing an IC200UEX636-C module?
Before replacement, verify the VersaMax Micro PLC compatibility, AC power supply requirements, analog signal wiring, channel configuration, expansion bus connection, and PLC program settings to ensure correct operation.
