Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | HIMA |
| Model | X-COM 01 |
| Part Number | 985260000 |
| Product Type | HIMax Communication Module |
| System | HIMA HIMax |
| Communication | Ethernet + Fieldbus |
| Ethernet Ports | 4 × RJ-45 |
| Ethernet Standard | 10BASE-T / 100BASE-TX |
| Fieldbus Interfaces | 2 × 9-pin D-Sub, optional submodules |
| Supported Protocols | SafeEthernet and various standard protocols |
| Supply Voltage | 24 VDC (-15% to +20%) |
| Current Consumption | 0.25–0.46 A |
| Protection Class | IP20 |
| Operating Temperature | 0 to +60 °C |
| Storage Temperature | -40 to +85 °C |
| Humidity | Max. 95%, non-condensing |
| Dimensions (L × W × H) | 230 × 29.2 × 310 mm |
| Approx. Net Weight | 1.3 kg |
FAQ
FAQ
Q1: What is HIMA X-COM 01?
A: It is a HIMax communication module used for Ethernet and fieldbus communication.
Q2: What is the part number?
A: The part number is 985260000.
Q3: How many Ethernet ports does it have?
A: It has 4 × RJ-45 Ethernet ports, supporting 10BASE-T/100BASE-TX.
Q4: Does 985260000 include fieldbus modules?
A: No. X-COM 01 / 985260000 is the version without fieldbus submodules. Optional fieldbus modules are factory-installed and result in a different X-COM 010 XY designation.
Q5: What connector board is required?
A: The module forms a functional unit with the X-CB 001 02 connector board, which is purchased separately.
Q6: What is the power supply?
A: 24 VDC, with an allowable range of -15% to +20%. Current consumption is approximately 0.25–0.46 A.
Q7: What are the dimensions and weight?
A: Approximately 230 × 29.2 × 310 mm (L × W × H) and 1.3 kg.
Q8: Is X-COM 01 a safety I/O module?
A: No. It is a communication module. It does not execute the safety control logic itself; its function is to provide communication between the HIMax system and external systems/networks.
