Technical Specifications
| Parameter | Description |
|---|---|
| Module Type | Analog Output Module (4 Channels) |
| Output Type | Current output, range 0 to 21.8 mA |
| Outputs per Module | 4 isolated current outputs |
| Load Resistance | 750 Ohms maximum |
| Channel Isolation | 500 VDC (Channel to Channel) |
| Logic Isolation | 600 VDC (Channel to Logic) |
| Minimum Output Current | > 3.5 mA per channel |
| Accuracy | ±0.1% Full Scale at reference conditions |
| D/A Resolution | 12-bit |
| Output Update Rate | Synchronous with control execution |
| Calibration | Factory + per-channel field calibration |
| Failsafe Capability | User-defined failsafe output on comm. loss |
| Output Verification | Controller feedback indicates output flow |
| Max Modules per Rack | 10 (up to 12 with de-rating) |
| Power Requirements | 5V: Max 40 mA 24V: Max 200 mA |
| Dimensions (HxWxD) | 137 x 35.6 x 137.16 mm |
| Weight | 0.397 kg |
FAQ
FAQ
Q1: What type of output signal does the 900B01-0001 module support?
A1: It supports 0 to 21.8 mA current output per channel, configurable to any range within that span.
Q2: Is each channel electrically isolated?
A2: Yes, each output channel is isolated at 500 VDC from other channels.
Q3: Does the module have failsafe functionality?
A3: Yes, users can configure a failsafe output value that activates if communication with the controller is lost.
Q4: What is the output accuracy of the module?
A4: The module provides ±0.1% full-scale accuracy under reference conditions.
Q5: How many 900B01-0001 modules can be installed per rack?
A5: Up to 10 modules can be installed per rack (12 if temperature derating is applied).
Q6: Is the module hot-swappable?
A6: Yes, the ControlEdge HC900 platform supports module removal and insertion under power.
Q7: What is the maximum load resistance per output?
A7: Each output can support up to 750 Ohms load resistance.
Q8: What are the dimensions and weight of the module?
A8: The dimensions are 137 x 35.6 x 137.16 mm, and it weighs 0.397 kg.
