Technical Specifications
| Parameter | Description |
|---|---|
| Product Range | Modicon Quantum Automation Platform |
| Product or Component Type | Power Supply Module |
| Power Supply Type | Summable |
| Input Voltage | 48…60 V DC |
| Input Current | 3800 mA |
| Inrush Current | 14 A at 40 V |
| Maximum Input Power Interruption | 13 ms at 48 V |
| Associated Fuse Rating | 2 A, time-lag |
| Output Voltage | 5.1 V DC |
| Power Supply Output Current | 8 A summable |
| Output Overvoltage Protection | Internal |
| Output Overload Protection | Internal |
| Power Dissipation | 15.6 W |
| Alarm Output | 1 NC contact, 6 A, 220 V for power supply fault |
| Local Signalling | 1 LED (green) for power (PWR OK) |
| Marking | CE |
| Module Format | Standard |
| Net Weight | 0.65 kg |
| Dimensions | 103.9 × 40.3 × 250 mm |
| Protective Treatment | Conformal coating Humiseal 1A33 |
| Standards | CSA C22.2 No 142, UL 508 |
| Product Certifications | cUL |
| Electrostatic Discharge Resistance | 4 kV contact, 8 kV air, conforming to IEC 801-2 |
| Electromagnetic Field Resistance | 10 V/m, 80–2000 MHz, conforming to IEC 801-3 |
| Ambient Air Temperature for Operation | 0…60 °C |
| Ambient Air Temperature for Storage | -40…85 °C |
| Relative Humidity | 95% non-condensing |
| Operating Altitude | ≤ 5000 m |
FAQ
FAQ
Q1: What is the input voltage range supported by this module?
A1: The supported input voltage range is 48 to 60 V DC.
Q2: What is the maximum output current of the module?
A2: The output current is 8 A and it is summable.
Q3: Does the module provide overload protection?
A3: Yes, it includes internal output overload protection.
Q4: What type of alarm output does this module have?
A4: It offers one normally closed (NC) contact, 6 A, 220 V, for power fault indication.
Q5: What are the physical dimensions of the module?
A5: The dimensions are 103.9 × 40.3 × 250 mm.
Q6: What is the inrush current capability of this module?
A6: It can handle up to 14 A at 40 V.
Q7: Does the module offer electromagnetic interference resistance?
A7: Yes, it conforms to IEC 801-3 and can withstand 10 V/m (80–2000 MHz).
Q8: What is the acceptable ambient operating temperature range?
A8: The module operates within 0 to 60 °C ambient temperature.
