Technical Specifications
| Parameter | Description |
|---|---|
| Range of Product | Modicon Quantum automation platform |
| Product or Component Type | VAC discrete input module |
| Compatible Software | ProWORX 32, Unity Pro, Concept |
| Discrete Input Points | 32 |
| Group of Channels | 4 groups |
| Addressing Requirement | 2 input words |
| Discrete Input Voltage | 24 V AC |
| Input Current | 11.1 mA (57…63 Hz) 13.2 mA (47…53 Hz) |
| Voltage State 1 Guaranteed | 12…30 V AC (57…63 Hz) 14…30 V AC (47…53 Hz) |
| Voltage State 0 Guaranteed | 0…5 V (57…63 Hz) 0…5 V (47…53 Hz) |
| Input Impedance | 2600 Ohm capacitive (57…63 Hz) 3100 Ohm capacitive (47…53 Hz) |
| Network Frequency Limits | 47…63 Hz |
| Maximum Leakage Current | 1.9 mA |
| Absolute Maximum Input | 30 V continuous 32 V for 10 seconds 50 V for 1 cycle |
| Response Time | 4.9…0.75 ms × line cycle (Off-On) 7.3…12.3 ms (On-Off) |
| Isolation Between Channels | 1780 Vrms for 1 minute |
| Isolation Group to Bus | 1780 Vrms for 1 minute |
| Bus Current Requirement | 250 mA |
| Maximum Power Dissipation | 10.9 W |
| Local Signaling | 1 green LED (Active), 1 red LED (Fault), 32 green LEDs (input status) |
| Marking | CE |
| Module Format | Standard |
| Dimensions (H × W × D) | 103.9 × 40.3 × 250 mm |
| Weight | 0.34 kg |
| Protective Treatment | Conformal coating Humiseal 1A33 |
| Standards | CSA C22.2 No 142, UL 508 |
| Product Certifications | FM Class 1 Division 2, cUL |
| ESD Immunity | 4 kV contact IEC 801-2 8 kV air IEC 801-2 |
| Electromagnetic Immunity | 9.1 V/m (10 V/m) 80–2000 MHz IEC 801-3 |
| Operating Temperature | 0…60 °C (32…140 °F) |
| Storage Temperature | -40…85 °C (-40…185 °F) |
| Relative Humidity | 95% non-condensing |
| Operating Altitude | ≤ 5000 m (16404.2 ft) |
FAQ
FAQ
Q1: How many discrete input channels does the 140DAI35300C module support?
A1: It supports 32 AC discrete input channels.
Q2: What is the input voltage range for this module?
A2: It operates at 24 V AC. Voltage state 1 is guaranteed between 12–30 V AC (57–63 Hz) or 14–30 V AC (47–53 Hz).
Q3: What is the module’s response time?
A3: Off-to-On response time is 0.75–4.9 ms, and On-to-Off is 7.3–12.3 ms.
Q4: What is the input current for the 140DAI35300C?
A4: It is 11.1 mA at 57–63 Hz and 13.2 mA at 47–53 Hz.
Q5: Does the module include status LEDs?
A5: Yes, it has 32 green LEDs for input status, 1 green LED for bus activity, and 1 red LED for fault detection.
Q6: What kind of protective treatment does the module have?
A6: It has a conformal coating using Humiseal 1A33.
Q7: What are the module’s dimensions and weight?
A7: The dimensions are 103.9 × 40.3 × 250 mm, and it weighs 0.34 kg.
Q8: What is the maximum operating altitude for the 140DAI35300C?
A8: It can operate at altitudes up to 5000 meters (16404.2 feet).
