Technical Specifications
| Parameter | Description |
|---|---|
| Range of product | Modicon Quantum automation platform |
| Product or component type | Power supply module |
| Power supply type | Redundant |
| Input voltage | 48…60 V DC |
| Input current | 3800 mA |
| Inrush current | 14 A at 40 V |
| Maximum input power interruption | 13 ms at 48 V |
| Associated fuse rating | 2 A, time-lag |
| Output voltage | 5.1 V DC |
| Power supply output current | 8 A redundant |
| Output overvoltage protection | Internal |
| Output overload protection | Internal |
| Power dissipation | 17.2 W |
| Alarm output | 1 NC, 6 A, 220 V power supply fault |
| Local signalling | 1 green LED for power (PWR OK) |
| Module format | Standard |
| Marking | CE |
| Product certifications | cUL |
| Standards | CSA C22.2 No 142, UL 508 |
| Resistance to electrostatic discharge | 4 kV contact, 8 kV air (IEC 801-2 compliant) |
| Resistance to electromagnetic fields | 10 V/m, 80…2000 MHz (IEC 801-3 compliant) |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95%, non-condensing |
| Operating altitude | ≤ 5000 m |
| Dimensions (W × H × D) | 103.9 × 40.3 × 250 mm |
| Net weight | 0.65 kg |
FAQ
FAQ
Q1: What input voltage range does the 140CPS42400 support?
A1: It supports an input voltage range of 48 to 60 V DC.
Q2: Does the module have redundant power support?
A2: Yes, the 140CPS42400 is a redundant power supply module.
Q3: What is the maximum allowable power interruption time?
A3: Up to 13 milliseconds at 48 V input.
Q4: What are the output voltage and current ratings?
A4: The output voltage is 5.1 V DC and the output current is 8 A (redundant).
Q5: Is the module protected against overvoltage and overload?
A5: Yes, it includes internal overvoltage and overload protection.
Q6: What types of status indication and alarms are available?
A6: It includes a green LED (PWR OK) and a normally closed alarm output.
Q7: What is the operating temperature range of this module?
A7: The module operates between 0 and 60 °C.
Q8: What are the dimensions and weight of the module?
A8: Dimensions are 103.9 × 40.3 × 250 mm, and the weight is 0.65 kg.
