Technical Specifications
| Parameter | Description |
|---|---|
| Product Type | Electromechanical Relay Sub Base |
| Model | ABE7R16S210 |
| Relay Type | Soldered relay interface base for industrial control |
| Number of Channels | 16-channel relay interface |
| Contact Type | SPDT electromechanical relay contacts |
| Rated Control Voltage | 24 V DC (typical for compatible relay coils) |
| Output Switching | Designed for discrete signal switching in automation systems |
| Terminal Type | Screw-clamp terminals |
| Mounting Method | DIN rail mounting |
| Indicators | Individual LED indicators for relay status |
| Compatibility | Works with Schneider interface and distributed I/O systems |
| Insulation | Reinforced insulation for electrical safety |
| Application | Used for PLC signal expansion, machine control, and automation wiring |
| Dimensions | 206 × 77 × 71 mm |
| Weight | 0.405 kg |
FAQ
FAQ
Q1: What is the main function of the ABE7R16S210 relay sub base?
A1: It functions as a relay interface module to switch discrete control signals in automation systems.
Q2: Does each channel have its own LED status indicator?
A2: Yes, each of the 16 relay channels includes an LED to indicate activation status.
Q3: What type of terminals are provided for wiring?
A3: The module uses screw-clamp terminals for secure and reliable connections.
Q4: Is the ABE7R16S210 suitable for DIN rail mounting?
A4: Yes, it is designed for standard DIN rail installation within control panels.
Q5: Can this module be used with PLC output modules?
A5: Yes, it is commonly paired with PLC output modules to extend signal handling capability.
Q6: What type of relay contacts does the unit support?
A6: It supports SPDT electromechanical relay contacts for discrete switching.
Q7: Does the module provide electrical isolation between channels?
A7: Yes, reinforced insulation is included to ensure safe separation of channels.
Q8: How are relay states monitored during operation?
A8: Relay activity can be easily monitored through the built-in LED indicators on each channel.
