Technical Specifications
| Item | Specification |
|---|---|
| Product Name | Schneider Electric BMXSAI0410 |
| Product Type | Safety Analog Input Module |
| Product Series | Modicon X80 Safety |
| Analog Input Channels | 4 Isolated Channels |
| Input Signal Type | 4–20 mA Current |
| Input Level | High Level |
| Input Impedance | 286 Ω |
| Analog-to-Digital Conversion | 16-bit |
| Effective Resolution | 13-bit (0–12,500 Counts) |
| Measurement Resolution | 2 µA |
| Maximum Conversion Range | 0–25 mA |
| Digital Value Format | ±32,000 (User Scale), ±10,000 (Default) |
| Nominal Read Cycle Time | 6 ms for 4 Channels |
| Measurement Accuracy | ≤ 0.3% of Full Scale |
| Temperature Drift | 30 ppm/°C |
| Crosstalk Attenuation | ≥ 120 dB |
| Channel-to-Channel Isolation | 500 V DC |
| Channel-to-Ground Isolation | 1500 V DC |
| Channel-to-Bus Isolation | 1500 V DC |
| Current Consumption | 200 mA at 3.3 V DC; 115 mA at 24 V DC |
| MTBF | 463,000 Hours |
| Status Indicators | RUN, ERR, I/O Fault, Channel Diagnostics LEDs |
| Protection Rating | IP20 |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5%–95% Non-Condensing |
| Vibration Resistance | 3 gn |
| Shock Resistance | 15 gn |
| Operating Altitude | 0–2000 m (up to 5000 m with derating) |
| Certifications | TÜV, UL, CSA, ATEX, IECEx, EAC, RCM |
| Compatibility | Modicon M580 Safety CPU Systems |
| Electrical Connection | 20-Way Removable Terminal Block |
| Dimensions (W × H × D) | 32 × 131 × 86 mm |
| Weight | 0.143 kg |
| Country of Origin | France |
FAQ
FAQ
Q1: What is the BMXSAI0410 used for?
The BMXSAI0410 is a safety analog input module used to acquire and monitor 4–20 mA signals from field instruments in safety-critical automation applications. It is commonly deployed in process industries requiring functional safety compliance.
Q2: How many input channels does the module provide?
The module offers four fully isolated analog input channels, allowing independent monitoring of multiple safety-related process signals.
Q3: What signal type does the BMXSAI0410 support?
It is designed specifically for 4–20 mA current-loop signals, which are widely used by transmitters, sensors, and process instruments.
Q4: Is the BMXSAI0410 suitable for SIL-rated safety applications?
Yes. The module is designed for use in Modicon M580 Safety systems and supports safety architectures capable of achieving SIL3 and Performance Level e (PLe) when properly configured.
Q5: What level of isolation does the module provide?
The module provides 500 V DC isolation between channels and 1500 V DC isolation between channels, ground, and the backplane bus, helping reduce electrical interference and improve system reliability.
Q6: What are the dimensions and weight of the BMXSAI0410?
The module measures approximately 32 × 131 × 86 mm and has a net weight of 0.143 kg, making it suitable for installation in standard Modicon X80 racks.
Q7: Can the module be replaced while the system is running?
Yes. The BMXSAI0410 supports hot-swapping in compatible M580 Safety systems, allowing maintenance activities to be performed with minimal disruption to operations.
Q8: Which industries commonly use the BMXSAI0410?
The module is widely used in oil and gas, chemical processing, power generation, water treatment, mining, and other industrial environments where safety-certified analog signal monitoring is required.
