Technical Specifications
| Parameter | Description |
|---|---|
| Product Range | Modicon X80 |
| Accessory Type | Backplane Rack (with Ethernet interface) |
| Number of Slots | 4 slots: Bus X, Ethernet, CPU, Power, I/O modules |
| Module Compatibility | I/O modules, BMX processor, BME processor, Power supply, Application-specific modules |
| Electrical Connection | 1 XBE expansion connector |
| Mounting Options | Panel mounting (4 screws 4.32–6.35 mm) Plate mounting (4 M6 screws) 35 mm symmetrical DIN rail |
| Power Consumption | 162 mW @ 3.3 V DC 2.8 W @ 24 V DC |
| Current Consumption | 49 mA @ 3.3 V DC 118 mA @ 24 V DC |
| Dimensions (WxHxD) | 242.4 x 105.11 x 19 mm |
| Weight | 0.705 kg (1.554 lb) |
| Degree of Protection | IP20 |
| Operating Temperature | 0 to 60 °C (32 to 140 °F) |
| Relative Humidity | 5% to 95% non-condensing |
| MTBF Reliability | 1,588,025 hours |
| Compliance Standards | 2014/35/EU Low Voltage Directive 2014/30/EU EMC Directive |
FAQ
Frequently Asked Questions (FAQ)
Q1: What types of modules are supported by the BMXXEP0400?
A1: It supports Modicon X80 I/O modules, BMX processors, BME processors, power supplies, and application-specific modules.
Q2: Can the BMXXEP0400 be mounted on a DIN rail?
A2: Yes, it supports 35 mm symmetrical DIN rail mounting.
Q3: How many slots are available in the BMXXEP0400 rack?
A3: The rack provides 4 slots for bus, Ethernet, CPU, and I/O connections.
Q4: What is the power consumption of this backplane?
A4: It consumes 162 mW at 3.3 V DC and 2.8 W at 24 V DC.
Q5: What are the physical dimensions of the product?
A5: The dimensions are 242.4 mm x 105.11 mm x 19 mm.
Q6: What is the protection rating of the BMXXEP0400?
A6: The protection rating is IP20, suitable for enclosed cabinet installations.
Q7: What mounting methods are supported?
A7: It supports panel mounting with screws, plate mounting with M6 screws, and DIN rail mounting.
Q8: What is the MTBF of the product?
A8: The Mean Time Between Failures (MTBF) is 1,588,025 hours.
