Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Schneider Electric TM241CE40R |
| Manufacturer | Schneider Electric |
| Product Series | Modicon M241 |
| Product Type | Compact Logic Controller / PLC |
| Integrated I/O | 40 points |
| Digital Inputs | 24 |
| Fast Inputs | 8 |
| Digital Outputs | 16 |
| Relay Outputs | 12 |
| Fast Transistor Outputs | 4 |
| Output Type | Relay + PNP transistor |
| Relay Output Voltage | 5–250 VAC / 5–125 VDC |
| Relay Output Current | 2 A per output |
| Transistor Output Voltage | 24 VDC |
| Transistor Output Current | 0.5 A |
| Fast Output Current | 0.1 A in PTO mode |
| Supply Voltage | 100–240 VAC |
| Supply Voltage Range | 85–264 VAC |
| Supply Frequency | 50/60 Hz |
| High-Speed Counter | Up to 200 kHz |
| Pulse Train Output | 4 PTO outputs, up to 100 kHz |
| Ethernet | Yes |
| Ethernet Port | RJ45 |
| Serial Communication | 2 serial ports |
| Serial Interfaces | RS232 / RS485 |
| USB Interface | Mini-B USB |
| SD Card | Supported |
| Communication Protocols | Modbus TCP, Modbus RTU/ASCII, Ethernet/IP |
| Web Server | Yes |
| Local I/O Expansion | Up to 7 modules |
| Remote I/O Expansion | Up to 14 modules |
| Programming Software | EcoStruxure Machine Expert |
| Programming Standard | IEC 61131-3 |
| Mounting | 35 mm DIN rail / panel mounting |
| Protection Rating | IP20 |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -25°C to +70°C |
| Dimensions | 190 × 90 × 95 mm (W × H × D) |
| Product Weight | Approx. 0.62 kg |
FAQ
FAQ
Q1: What is the Schneider Electric TM241CE40R used for?
A: It is a Modicon M241 PLC designed for industrial machine automation, packaging equipment, conveyors, assembly systems, positioning and OEM machinery.
Q2: How many I/O points does the TM241CE40R have?
A: It provides 40 integrated I/O points, including 24 digital inputs and 16 outputs.
Q3: What type of outputs does the TM241CE40R use?
A: It combines 12 relay outputs with 4 fast PNP transistor outputs. The relay outputs are rated at 2 A, while the transistor outputs are rated at 0.5 A.
Q4: What power supply does the TM241CE40R require?
A: The controller requires a 100–240 VAC power supply, with an operating range of 85–264 VAC at 50/60 Hz.
Q5: Does the TM241CE40R support high-speed functions?
A: Yes. It provides 8 fast inputs, high-speed counting and 4 PTO outputs for pulse-control applications.
Q6: What communication interfaces are available?
A: The TM241CE40R provides Ethernet, two serial communication ports and a Mini-B USB programming port.
Q7: Can the TM241CE40R be expanded?
A: Yes. It supports up to 7 local I/O expansion modules and 14 remote I/O expansion modules.
Q8: What are the dimensions and weight of the TM241CE40R?
A: The PLC measures approximately 190 × 90 × 95 mm (W × H × D) and weighs approximately 0.62 kg.
