Technical Specifications
| Item | Specification |
|---|---|
| Model | TM2DDO32UK |
| Product Name | Discrete Output Module |
| Manufacturer | Schneider Electric |
| Series | Modicon TM2 |
| Product Type | Digital output module |
| Number of Outputs | 32 channels |
| Output Type | Relay / Discrete |
| Output Voltage | 24 V DC / 120 V AC selectable |
| Max Output Current | 0.5 A per channel |
| Electrical Isolation | Channel-to-backplane isolation |
| Status Indication | LED indicator for each output |
| Diagnostic Features | Short-circuit and load monitoring |
| Output Configuration | Sink/source configurable |
| Wiring Type | Spring terminal |
| Mounting Method | TM2 rack mounting |
| Protection Functions | Overvoltage, short-circuit protection |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| EMC Compliance | Industrial EMC standards |
| Dimensions (L × W × H) | 81.3 x 90 x 33.5 mm |
| Weight | 0.105 kg |
FAQ
FAQ
Q1: What types of devices can be controlled by this module?
A1: It can switch discrete devices such as solenoids, relays, lamps, and contactors compatible with its voltage and current ratings.
Q2: How are the output states indicated?
A2: Each output channel has an LED indicator showing the ON/OFF status in real-time.
Q3: Can the module handle both AC and DC loads?
A3: Yes, it supports both 24 V DC and 120 V AC outputs, configurable according to application needs.
Q4: Is there built-in protection against short circuits?
A4: Yes, each output is protected against short circuits and overcurrent conditions to prevent damage.
Q5: Can the output configuration be changed in the field?
A5: The module allows sink/source configuration to adapt to different load types.
Q6: Does the module provide diagnostic feedback to the controller?
A6: Yes, it reports load status and fault conditions back to the controller for monitoring.
Q7: Is the module suitable for industrial environments with electrical noise?
A7: Yes, it is designed with EMC compliance to ensure reliable operation in harsh industrial environments.
Q8: How are the outputs wired to field devices?
A8: Outputs are connected via spring terminals that provide secure and reliable wiring.
