Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Digital Valve Positioner |
| Model Number | Woodward 8200-188 |
| Dimensions | 261 × 173 × 57 mm |
| Weight | 2.6 kg |
| Function | Controls and positions valves precisely in turbine and engine control systems |
| Control Type | Digital microprocessor-based control |
| Input Signal | 4–20 mA, HART compatible |
| Output Signal | 4–20 mA or PWM for actuator control |
| Power Supply | 24 V DC nominal |
| Power Consumption | ≤ 6 W |
| Feedback Type | Position sensor (linear or rotary) |
| Communication Protocols | HART, Modbus RTU |
| Valve Type Compatibility | Linear and rotary actuators |
| Positioning Accuracy | ±0.2% of full stroke |
| Response Time | < 100 ms |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -50°C to +90°C |
| Enclosure Rating | IP65 / NEMA 4X |
| Material | Aluminum housing with corrosion-resistant coating |
| Mounting Type | Field-mountable, compatible with standard actuator interfaces |
| Vibration Resistance | 10 g, 10–2000 Hz |
| EMC Compliance | IEC 61326-3-1 industrial standard |
| Application Areas | Turbine control, steam valve actuation, process control systems |
FAQ
FAQ
Q1: What is the main function of the Woodward 8200-188 Digital Valve Positioner?
A1: The 8200-188 precisely controls the position of valves based on input control signals, ensuring optimal flow regulation in turbine and process control systems.
Q2: What type of input signals does this positioner support?
A2: It supports standard 4–20 mA analog signals and HART communication for advanced diagnostics and configuration.
Q3: Is the 8200-188 compatible with both linear and rotary actuators?
A3: Yes, it is designed to work seamlessly with both linear and rotary actuator types.
Q4: How accurate is the valve positioning control?
A4: The device provides high positioning accuracy of ±0.2% of the full stroke, ensuring precise valve response and control stability.
Q5: What communication options are available for integration?
A5: The unit offers HART and Modbus RTU communication protocols, making it suitable for integration into various control systems.
Q6: How does the positioner perform in harsh industrial environments?
A6: It features a rugged IP65-rated aluminum enclosure and is built to operate reliably across a wide temperature range and under strong vibration.
Q7: What kind of feedback sensor does it use?
A7: It supports either linear or rotary position sensors to provide real-time feedback for precise valve control.
Q8: What industries typically use the Woodward 8200-188?
A8: It is commonly used in turbine control, power generation, steam valve systems, and other industrial automation applications requiring reliable valve actuation.
