Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 8400-016 |
| Manufacturer | Woodward |
| Product Type | Electronic Speed Controller |
| Function | Maintains precise engine speed by controlling fuel actuator output |
| Input Signal | Magnetic pickup or frequency signal (0.5–120 V RMS) |
| Speed Range | 500 to 15,000 RPM |
| Output Type | Pulse-width modulated (PWM) or analog DC |
| Control Accuracy | ±0.25% steady-state speed regulation |
| Power Supply Voltage | 18–32 V DC |
| Power Consumption | < 10 W |
| Start Fuel Limit | Adjustable 0–100% |
| Speed Trim Range | ±10% of rated speed |
| Idle Speed Adjustment | Independent via onboard potentiometer |
| Maximum Speed Setting | Adjustable via internal trim |
| Dynamic Response Time | < 50 ms |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -55°C to +100°C |
| Vibration Resistance | 5 g, 10–500 Hz |
| Humidity | Up to 95% RH, non-condensing |
| Protection Class | IP20 |
| Certifications | CE, UL, CSA |
| Applications | Diesel/gas engines, generator sets, turbines, and industrial speed control systems |
| Dimensions | 210 x 160 x 75 mm |
| Weight | 2.2 kg |
FAQ
FAQ
Q1: What is the main purpose of the Woodward 8400-016 Speed Controller?
It controls engine speed by adjusting the actuator output based on feedback from a speed sensor or magnetic pickup.
Q2: What types of input signals can this controller accept?
It accepts AC frequency input signals from magnetic pickups, typically between 0.5 and 120 V RMS.
Q3: What is the supported engine speed range?
The controller supports engine speeds from 500 to 15,000 RPM for a wide variety of industrial and power applications.
Q4: How accurate is the Woodward 8400-016 in maintaining speed?
It provides a steady-state regulation accuracy of ±0.25%, ensuring stable speed under varying load conditions.
Q5: What voltage is required to power the controller?
The 8400-016 operates on a DC power supply ranging from 18 to 32 volts.
Q6: How fast does the controller respond to load or speed changes?
It offers a response time of less than 50 milliseconds, allowing rapid correction to maintain target speed.
Q7: Can the idle and maximum speeds be adjusted separately?
Yes, both idle and maximum speeds can be independently adjusted using built-in trim potentiometers.
Q8: Under what environmental conditions can this controller operate?
It functions reliably in ambient temperatures from -40°C to +85°C and in up to 95% relative humidity environments.
