Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AAI543-H53 S1 |
| Type | Analog Output Module (Current Output, Isolated) |
| Number of Output Channels | 16, isolated |
| Output Signal | 4 to 20 mA |
| Withstanding Voltage | Between output and system: 1500 V AC, 1 minute |
| Allowable Load Resistance | 0 to 750 Ω |
| Circuit-open Detection | Less than 0.65 mA |
| Accuracy | ±48 μA |
| Data Update Period | 10 ms |
| Temperature Drift | ±16 μA / 10°C |
| Maximum Current Consumption | 230 mA (5 V DC), 540 mA (24 V DC) |
| External Connection | Pressure clamp terminal, MIL connector cable, dedicated cable (KS1) |
| HART Communication | Available |
| Dimensions | 107.5 × 32.8 × 130 mm |
| Weight | 0.4 kg |
FAQ
FAQ
Q1: How many output channels does this module support?
A1: This module supports 16 isolated analog current output channels.
Q2: What is the output signal range?
A2: The output signal range is 4 to 20 mA.
Q3: What is the allowable load resistance range?
A3: The allowable load resistance range is 0 to 750 Ω.
Q4: What is the accuracy of the module?
A4: The accuracy is ±48 μA.
Q5: What is the data update period?
A5: The data update period is 10 milliseconds.
Q6: Does the module support HART communication?
A6: Yes, the module supports HART communication.
Q7: What is the withstanding voltage capability?
A7: The withstanding voltage between output and system is 1500 V AC for 1 minute.
Q8: What are the dimensions and weight of the module?
A8: The dimensions are 107.5 × 32.8 × 130 mm, and the weight is 0.4 kg.
