Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ADV551-P13/D5A00 |
| Number of Output Channels | 32 |
| Rated Applied Voltage | 24 V DC |
| External Power Supply Rating | 24 V DC, 50 mA |
| External Power Supply Voltage Range | 20.4 to 26.4 V DC |
| Output ON Voltage (Max.) | 2 V DC |
| Leak Current (Max., Output OFF) | 0.1 mA |
| Output Format | Current sink |
| Maximum Load Current | 100 mA/channel, 26.4 V |
| Withstanding Voltage | Between output signal and system: 2 kV AC, 1 min; Between commons: 500 V AC, 1 min, common minus side every 16-channel |
| Functions | ON/OFF status output, one-shot pulse width output, time-proportioning ON/OFF output |
| Output Response Time | ≤ 3 ms (status output), ≤ 10 ms (mixed status and pulse outputs) |
| Pulse Width Range | 8 ms to 7200 s |
| Pulse Width Resolution | 8 ms (ON/OFF delay max. 1 ms) |
| Maximum Current Consumption | 700 mA (5 V DC), 60 mA (external power) |
| External Connection | Pressure clamp terminal, KS cable interface adapter, MIL connector cable |
| Dimensions | 107.5 × 130 × 32.8 mm |
| Weight | 0.2 kg |
FAQ
FAQ
Q1: How many output channels does this module have?
A1: This module provides 32 output channels.
Q2: What is the rated applied voltage?
A2: The rated applied voltage is 24 V DC.
Q3: What is the maximum load current?
A3: The maximum load current is 100 mA per channel at 26.4 V.
Q4: What is the output format type?
A4: It uses a current sink output format.
Q5: What is the pulse width output range?
A5: The pulse width can be set between 8 ms and 7200 s.
Q6: What are the dimensions and weight of the module?
A6: The dimensions are 107.5 × 130 × 32.8 mm, and the weight is 0.2 kg.
Q7: What external connection options are available?
A7: It can be connected via pressure clamp terminal, KS cable interface adapter, or MIL connector cable.
Q8: What is the output response time?
A8: The response time is up to 3 ms for status output and up to 10 ms for mixed status and pulse outputs.
