Technical Specifications
| Item | Specification |
|---|---|
| Model | NFAI143-S50 |
| Number of Input Channels | 16-channel isolated input |
| Input Signal | 4 to 20 mA DC current |
| Allowable Input Current | Max. 24 mA |
| Withstanding Voltage | 1500 V AC between input and system (1 min) |
| Overcurrent Protection | Provided |
| Input Resistance (ON) | 250 Ω |
| Input Resistance (OFF) | 500 kΩ or more |
| Accuracy | ±0.1% of full scale |
| Data Refresh Cycle | 10 ms |
| Input Step Response Time | 100 ms |
| Transmitter Power Supply | 24.0 to 25.5 V (output current limit: 25 mA) |
| 2-/4-Wire Setting | Settable per channel by pin |
| Temperature Drift | Max. ±0.01%/°C |
| Max Current Consumption (5V) | 230 mA |
| Max Current Consumption (24V) | 540 mA |
| External Connection | Pressure clamp terminal or MIL connector |
| HART Communication | Available |
| Dimensions | 130 x 107.5 x 32.8 mm |
| Weight | 0.3 kg |
FAQ
FAQ
Q1: Does the NFAI143 module support HART communication?
A1: Yes, it supports HART protocol for integration with HART-enabled field devices.
Q2: Are the input channels of the NFAI143 isolated?
A2: Yes, all input channels are isolated from the system, with a 1500 V AC withstand voltage.
Q3: Can each channel be configured individually for 2-wire or 4-wire transmitters?
A3: Yes, each channel can be individually configured via a setting pin.
Q4: What is the input resistance when the module is powered off?
A4: The input resistance is 500 kΩ or more when powered off.
Q5: What are the power requirements for the module?
A5: It requires 5 V DC (230 mA) and 24 V DC (540 mA) power supplies.
Q6: What is the maximum allowable input current?
A6: The module can accept input currents up to 24 mA.
Q7: Is overcurrent protection included in the NFAI143?
A7: Yes, the module includes overcurrent protection to safeguard the inputs.
Q8: What is the measurement accuracy of the module?
A8: The accuracy is ±0.1% of full scale, suitable for precision monitoring.
