Manufacturer：Allen Bradley
Product Number：1762-IT4
Product Type：Thermocouple / Millivolt Analog Input Module
Origin：USA
Dimensions：87 mm × ~40 mm × ~90 mm
Weight ：0.22 kg
FAQ
FAQ
Q1. What is the primary function of this module?
It is a thermocouple/millivolt analog input expansion module for MicroLogix 1200 PLCs.
Q2. How many input channels does the 1762‑IT4 provide?
It provides four input channels plus a cold junction compensation sensor.
Q3. Which thermocouple types does it support?
It supports J, K, T, E, R, S, B, N, and C thermocouples and ±50 mV/±100 mV millivolt signals.
Q4. What is the input resolution?
The module uses 15‑bit plus sign resolution for analog inputs.
Q5. What are the operating temperature limits?
The module operates from 0 °C up to 55 °C.
Q6. How is the module powered and how much current does it draw?
It draws up to 40 mA at 5 V DC and 50 mA at 24 V DC from the PLC backplane.
Q7. What are the physical dimensions and weight?
The dimensions are approximately 90 mm × 40 mm × 87 mm and the weight is about 0.22 kg.
Q8. Can this module be mounted on standard DIN rail?
Yes, it is designed for DIN rail mounting in compatible PLC racks.
