Bently Nevada 170180-01-00 1034549-70 External Transducer I/O Module

FAQ

Q1: What is the primary function of the 170180‑01‑00 module?
A1: It serves as an external transducer I/O interface, connecting proximity probes or accelerometers to the FieldMonitor system, converting sensor signals into monitored data.

Q2: How many sensors can be connected to this module?
A2: Two sensors (one per channel) can be connected—either Proximitor sensors or accelerometers with –24 V bias.

Q3: What is the frequency response of this module?
A3: It maintains accuracy (within –5% error) for signal frequencies above 25 kHz.

Q4: What is the module’s operating temperature range?
A4: It operates reliably between –34 °C and +85 °C, with storage rated from –40 °C to +85 °C.

Q5: What is its power consumption?
A5: Without any transducer connected, it draws up to 2.0 mA of current.

Q6: What is the weight and size of the module?
A6: The module weighs approximately 277 g and measures 12.5 cm × 2.1 cm × 10.5 cm.

Q7: How does it handle sensor fault or overcurrent conditions?
A7: The module has a current limit setpoint between 33.6 mA and 37.6 mA to protect against sensor faults or overcurrent conditions.

Q8: What certifications or safety standards does it support?
A8: It is compliant with Ex nA IIC T4 standards (for Zone 2 / Class I Div 2 environments), ensuring safe use in hazardous areas.

170180-01-00 1034549-70 Bently Nevada
