GE DS200TCCBG1BED Extended Analog I/O Board

FAQ

Q1. What does the DS200TCCBG1BED do?
It’s an extended analog I/O board used in GE Speedtronic Mark V and TC2000 control systems to scale, condition, and manage multiple analog signals such as sensor currents and RTDs.

Q2. What types of signals can it process?
It processes current loops (e.g., 4–20 mA), small‑signal inputs (0–1 mA), RTD temperature inputs, generator/bus voltage inputs, and line current signals typically via terminal boards.

Q3. How is the board powered?
The board operates from a +5 V DC supply provided by the system backplane.

Q4. What processor does this board use?
It is built around an 80196 microprocessor that handles analog I/O scaling and processing.

Q5. How is DS200TCCBG1BED installed?
It mounts on a rack inside a Mark V or TC2000 control cabinet and connects to system terminal boards via ribbon or multi‑pin connectors.

Q6. Does it provide any visual status feedback?
Yes; it has a board‑mounted LED that indicates operational status for diagnostics.

Q7. What are its approximate size and weight?
The board is about 270 mm × 173 mm × 55 mm and weighs around 1.5 kg (3.3 lbs).

Q8. Is this board still in production?
No; it is a legacy analog I/O board from the GE Speedtronic Mark V series, typically found as stock surplus or refurbished instead of current production.
