Manufacturer：GE
Product Number：IS220PDIIH1B
Product Type：Discrete I/O Pack
Origin：USA
Dimensions：86.2 × 149 × 121 mm
Weight：0.5 kg
FAQ
FAQ
Q1: How many input channels does the IS220PDIIH1B module support?
A1: It supports 16 isolated discrete input channels.
Q2: What is the typical input voltage for IS220PDIIH1B?
A2: The nominal input voltage is 24 V DC, with a range of 18 to 32 V DC.
Q3: What is the input current per channel?
A3: Approximately 6 mA per channel at 24 V DC.
Q4: Does the module provide channel isolation?
A4: Yes, optical isolation is provided for each channel.
Q5: Does the module support diagnostic features?
A5: Yes, it supports channel-level diagnostics with fault detection.
Q6: What mounting options are supported?
A6: DIN rail or panel mounting is supported.
Q7: What communication interface does it use?
A7: It uses Ethernet-based IONet for communication.
Q8: What is the operating temperature range?
A8: -30°C to +65°C.
