Honeywell 2MLF-RD8A RTD Input Module 30-Day Returns

FAQ

Q1: What types of RTD sensors are supported by the Honeywell 2MLF-RD8A?
It supports standard RTD types like Pt100, Pt1000, Cu10, and Ni120.

Q2: How many wires per RTD input channel are supported?
It supports both 3-wire and 4-wire RTD configurations.

Q3: What is the temperature measurement range?
It supports a range from -200°C to +850°C.

Q4: What is the sampling rate per channel?
Each channel samples at 10 times per second.

Q5: Is hot-swapping supported?
No, the module must be powered down before replacement.

Q6: How does the module communicate with the system?
It communicates through the control system’s backplane bus.

Q7: What is the operating temperature range?
It operates between -10°C and +60°C.

Q8: What are the dimensions and weight of the module?
Dimensions are 245 x 87 x 68 mm, and it weighs 0.34 kg.

2MLF-RD8A Honeywell RTD Input Module
