OVATION 1C31125G03 HART Analog Input Module

FAQ

Q1: How many input channels does this module have?
A1: The module provides 8 analog input channels.

Q2: What is the input current range?
A2: The normal operating range is 4–20 mA, with user-configurable limits of 0–23 mA.

Q3: What is the sampling rate per channel?
A3: Each channel is sampled every 24 milliseconds.

Q4: Does the module provide channel-to-channel isolation?
A4: No channel-to-channel isolation, but there is 1000 VAC/VDC isolation between channel and logic.

Q5: What are the power requirements?
A5: Main power is 1.2 W typical (2.5 W max), and auxiliary power is 4.1 W typical (7.2 W max).

Q6: What is the operating temperature range?
A6: The module operates between 0°C and 60°C.

Q7: What are the dimensions and weight of the module?
A7: The module measures 200 × 150 × 50 mm and weighs 1.5 kg.

Q8: What is the required auxiliary power supply voltage?
A8: The auxiliary power supply voltage is 24 VDC, with an allowable range of -5% to +6.25%.

1C31125G03 HART Analog Input Module OVATION
